Dear Customer!

Thank you for your good choice! You purchased a Timberk oil filled radiator.

We did everything for the unit to operate reliably for a long time.

Timberk electric oil filled radiator is designed to heat the air and create a

comfortable  environment  indoors  during  cold  season  (early  spring,  fall,

winter).  The  radiator  is  very  easy-to-use,  easy  to  install,  and  also  has  an

increased  heat  transfer  and  an  efficient  air  flow  distribution.  Besides,

Timberk Professional oil filled radiators are additionally equipped with an

air ionizing function. The built-in air ionizer can operate independently of

the air heating mode.

You  must  install  the  oil  filled  radiator

only  vertically

  and  only  on  a  rigid

surface (for example, on the floor) in a place, where it is possible to connect

to ~220 V single-phase power supply wiring

with an earth circuit.

Lines of Timberk electric oil filled radiators, described in this

operation manual:
TOR 31  EH

X

I

(features a built-in fan heater)

TOR 31

RRX

(features a built-in fan heater)

TOR 21  BT

X

 I

TOR 21  HB

X

 I

TOR 21

SLX

 I

Please, read this manual prior to assembly and use of the unit!

Appearance and components.

1-front control panel

2-unit's operating mode indicator

3-thermostat regulator (thermostat's turning

knob)

4-heating power regulator (a turning knob to

select unit's operating power)

5-roller wheels to move the radiator (included in

the supply set)

6-air ionizer on/off button (located on the right

side of the unit)

7-Ionizer cap

8-unit's case front panel

9-radiator's oil containing sections

10-fan heater

11-cable holder

2

www.timberk.com

electric oil felled radiator

TOR 21... HBX I /

TOR 21... BTX I

1

4

2
3

7

8

5

1

TOR 21... EHX I

TOR 21... RRX

9

6

6

3

4

7

2

10

11

5

1

2

3
6
4

7

8
9
11
5

TOR 21... SLX I

1
3
2
4

9
10
8
11

5

9
