8.

Electric oil-illed radiator

EN

6. OPERATION

ATTENTION!

In order to increase the operational life of the oil radiator is recom-

mended to note the order unit is switched of. Shutting down the output

without precooling of the heating elements can cause overheating and
premature failure.

1. Read section «General safety rules» carefully unless you already did it.
2. Connect the unit’s power cord to an electric outlet, observing all of the abovementioned precau-
tions. Remember that you can connect the unit to electric mains only if the rotating power reg-

ulator is in OFF position (switched of), i.e. the knob is rotated against the stop counterclockwise.

3. It is also preferable to turn the temperature regulating knob against the stop counterclockwise.
Then you can connect the unit to electric mains.
4. Set the unit’s power regulator (knob) to position I, II or III (corresponds to low, normal and max-
imum power of unit’s operation). Remember that the higher the power you choose, the faster the
unit heats the air. But at a low power you save electric power and reduce the load on your electric
mains.

5. Ater you chose the desired operating power in accordance with your individual preferences, you

have to choose the desired heating temperature. Turning the thermostat knob clockwise (from
MIN position towards MAX position), you thus adjust the temperature mode you need. Since the
moment you choose the temperature mode (provided one or another power mode is activated see

item 4) the oil illed radiator will start to operate.
6.  During  the  irst  minutes  of  radiator’s  operation  you  may  fell  a  slight  smell  of  burning.  It  may

be caused by dust on the unit; it will soon disappear. If necessary, you can perform a preliminary
preventive cleaning of the unit, following rules, set forth in this manual and observing «General
safety rules».
7. When the room temperature will reach the desired level, you should slowly turn the temperature
regulator’s knob counterclockwise (towards MIN). You will hear a click of the thermostat turning

of, and the light on the  control panel will go out. Now the room temperature will be maintained

at the chosen level.
8. If you need to reduce the room temperature, turn the thermostat knob counterclockwise. Also
you can lower the unit’s operating power (I or II).
9. If you need to raise the room temperature, turn the thermostat knob clockwise (maximum pos-
sible position MAX indicator). Also you can raise the unit’s operating power (II or III).

10. The lines of Hyundai oil illed radiators HO2 series are additionally equipped with a built-in fan

heater, located on the front panel of the unit. To speed up the room heating, activate the fan heater
by pressing the special button switch (the button can be located both on the front panel of the unit

and on the side (to the let) of the front panel of the unit depending on the unit line).

Pressing the fan heater button, you must select the ON position (switched on), upon that pow-
er supply will be automatically fed both to the fan motor and to the built-in heating element. If
you need to turn on the fan heater, please, press the button again, selecting the OFF position

(switched of).
