8.

Electric infrared heater

EN

Connection to electric mains

1. The patio heater is designed to be connected to 230V~, 50Hz singlephase voltage mains with
a grounding circuit.
2. Prior to connection make sure that parameters of electric mains in the place of connection

comply with parameters, indicated on the identification plate with technical data of the unit.

3. It is necessary to follow active electrical safety precautions, connecting the convector to
electric mains.
4. An electric outlet must be properly grounded. The outlet must be designed for rated current
not less than 16A for models with maximum power up to 2000W. Electric outlet and plug
must always stay dry to prevent current leakage. Regularly check if the electric plug is tightly
connected to the outlet. It must be done in the following order: connect an electric plug into

an outlet, after half hour operation turn off the patio heater and disconnect the plug from the

outlet, check if the plug is heated by your hand. If the plug heated over 50°C then replace the

outlet  by  a  new  one  to  prevent  damages,  incidents,  fire  as  a  result  of  bad  electric  contact.  A
specialist must do the job.

7. OPERATION OF THE INFRARED HEATER

1. Before switching on the heater, ensure that no moisture on the device and on the heating element.

2. After the first turn the heater on may appear briefly burnt smell. This is normal. If the smell

persists for a long time, immediately disconnect the heater from the electric power supply and
contact your service representative.
3. To exclude the appearance of burnt smell when using the heater in the future it is
recommended to keep it clean, preventing the accumulation of dust on it.

4. Within several minutes after switching on the heater to the heating element may appear black
dots. This is normal and does not affect the operation of the device.

5. Not recommended for long look at heater heating element, this can cause deterioration and
damage to health.

WARNING!

Warning! Please connect the cable with an industrial plug rated

3P 230V 16A IP67 of IEC 60309-2.

WARNING!

After installation of the heater and before switching for the first time, it is

necessary to wipe the radiating board with alcohol. After that, it is PRO

-

HIBITED to touch the radiating board.

WARNING!

Slight crackles may be heard during operation at the moment of

heating or cooling, which disappear, when the heater reaches the

working mode.
