5.

Electric infrared heater

EN

Technical specifications

Table 1

Parameter

H-HC4-15

UI725

H-HC4-18

UI728

H-HC4-20

UI709

H-HC4-25

UI710

H-HC4-30

UI711

Rated  power
consumption,
W

1500

1800

2000

2500

3000

Power supply,
V/Hz

230~/50

230~/50

230~/50

230~/50

230~/50

Rated
current, A

6,5

7,8

8,7

10,9

13,0

Protection
class

IPX0

IPX0

IPX0

IPX0

IPX0

Electric pro-
tection class

Class I

Class I

Class I

Class I

Class I

Heating area,
m²

10-15

12-18

15-20

20-25

25-30

Net weight, kg

2,0

2,0

2,75

2,75

3,15

Device dimen-
sions, mm

605x90x190

605x90x190

865x90x190

865x90x190

1005x90x190

Main features

1. Significant economic effect as compared to convectional heating, where heat is significantly

consumed for heating of unused roof space (first, air is heated throughout the room volume, and

then air heats objects and surfaces in the room).

2. Capability of local heating only for those areas in the room, where it is necessary, without

heating of the whole room volume.

3.  Low  air  temperature  in  the  room  at  comfortable  temperature  on  surfaces  of  objects,  floor,

and walls creates the freshness effect air is not dried up.

4. Low convection (thermal movement of air volumes) reduces amount of dust kicked up from

the floor.

5. High protection class of the device (IP65) allows to apply the device in environments with the

most adverse conditions.

6. The possibility of using the device in a portable rack. (Portable stand comes separately as

accessory).

Area of application

Infrared heaters are designed for general, additional, and local heating of industrial, production,

utility,  and  similar  rooms  (flats,  offices,  trade  enterprises,  exercise  rooms,  educational  institu

-

tions, public catering enterprises, storage facilities, hangars, agricultural facilities, etc.) and can

be used outdoors.
