Maintenance

Since fan motors and other components are
maintenance free, no maintenance other than
cleaning is necessary, this can vary depending
on local conditions. Undertake cleaning
at least twice a year. Grille, impeller and
elements can be vacuum cleaned or wiped
using a damp cloth. Avoid the use of strong
alkaline or acidic cleaning agents.

Overheating

The air curtain unit with electric heater is
equipped with an overheat protector. If it is
deployed due to overheating, reset as follows:
1. Disconnect the electricity with the isolating

switch.

2. Allow the electrical coil to cool.
3. Determine the cause of overheating and

rectify the fault.

4. Reconnect the power and start the unit.

All motors are equipped with an integral
thermal safety cut-out. This will operate,
stopping the air curtain should the motor
temperature rise too high. The cut-out
will automatically reset when the motor
temperature has returned to within the
motor’s operating limits.

Fan replacement

1. Determine which of the fans is not

functioning.

2. Disconnect the cables to the relevant fan.
3. Remove the screws securing the fan and lift

the fan out.

4. Install the new fan in reverse order to the

above.

Replacing the electric coil

1. Mark and disconnect the cables to the

electric coil.

2. Remove the mounting screws securing the

coil in the unit and lift the coil out.

3. Install the new coil in reverse order to the

above.

Trouble shooting

If the fans do not run, check the following:
1. Operating power supply to the unit;

check fuses, circuit-breaker, time switch/
thermostat (if any) that starts and stops the
unit.

2. That the air flow selector is correctly set.
3. That the position limit switch is working (if

installed).

4. That the intake grille is not dirty.

If there is no heat, check the following:
1. Power supply to electric heater coil; check

fuses and circuit-breaker (if any).

2. That the heat demand exists; check

thermostat settings and actual temperature.

3. That the output selector (if any) is set

correctly.

4. That the intake grille is not dirty.

If the fault cannot be rectified, please contact
a qualified service technician.

Safety cut-out

(applies฀to฀units฀with฀electric฀heater)

If the installation is protected by means of a
safety cut-out, which trips when the appliance
is connected, this may be due to moisture
in the heating element. When an appliance
containing a heater element, has not been
used for a long period and is stored in a damp
environment, moisture can enter the element.

This should not be seen as a fault, but is

simply rectified by connecting the appliance
to the mains supply via a socket without a
safety cut-out, so that the moisture can be
driven out of the element. The drying time
can vary from a few hours to a few days.
As a preventive measure the unit should
occasionally be run for a short time when it is
not being used for extended periods of time.
