PA3500/4200

31

GB

Assembly and operating instructions

General Instructions

Read these instructions carefully before
installation and use. Keep this manual for
future reference.

The product may only be used as set out in
the assembly and operating instructions. The
guarantee is only valid if the product is used
in the manner intended and in accordance
with the instructions.

Application area

The Thermozone AR3500 air curtain unit
is supplied without heating, with electrical
heating or hot water heating

PA3500 is intended for entrances and

smaller doors up to 3.5 metres in height.

PA4200 is intended for larger door ways and

industrial door up to 4,2 metres in height.

Protection class for units with electrical
heating: IP20.
Protection class for units without heating and
units with water heating: IP21.

Operation

Air is drawn in at the top/rear of the unit and
blown out downwards/outwards so that it
shields the door opening and minimizes heat
loss. To achieve the optimum curtain effect
the unit must extend the full height/width of
the door opening.

The grille for directing exhaust air is

adjustable and is normally angled outwards to
achieve the best protection against incoming
cold air.

The efficiency of the air curtain depends

on the air temperature, pressure differences
across the doorway and any wind pressure.

NOTE! Negative pressure in the building
considerably reduces the efficiency of the air
curtain. The ventilation should therefore be
balanced.

Mounting

The air curtain range includes possiblities
for horizontal installation and for vertical
installation and the units can also be installed
recessed into suspended ceilings.

Horizontal mounting

The air curtain unit is installed horizontally
with the supply air grille facing downwards
as close to the door as possible. Minimum
distance from outlet to floor for electrically
heated units is 1800 mm. For other minimum
distances, see fig. 3.

For the protection of wider openings, several

units can be mounted next to each other
using a joining kit (fig. 8).

A design kit for a neat installation that

conceals cables, pipes and mountings
is available for both wall and ceiling
installations, se accessories pages.

Mounting with wall brackets PA34WB (fig. 5)

1.  Remove the plastic covers on the wall

brackets. (Fig. 5A)

2.  Mount the brackets on the wall according

to measures in fig. 5B.

3.  Fasten the hammer head screws on the

unit in the holes M8. (Fig. 4 and 5C)

4.  Lock the nuts so that the hammer head

screws are at 20 mm height. Note the
direction of the screw heads. (Fig. 5C)

5.  Slide the unit on the consoles. (Fig. 5D)
6.  Lock the nuts against the bracket and put

the plastic covers on again. (Fig. 5E)

Horizontal mounting on the ceiling

Threaded rods, wire suspension kits and
ceiling brackets for ceiling mounting are
available as accessories, see fig. 7 och 7 and
separate manuals.

Horizontal recessed mounting in false ceilings

Outlet extension used for recessed installation
is available as accessory, see fig. 9 and
separate manual.
