Thermozone AG  4500/5000 A/W

20

GB

General Instructions

Read these instructions carefully before
installation and use. Keep this manual for
future reference.

The guarantee is only valid if the
Thermozone units are used in the manner
intended by the manufacturer and in
accordance with the Frico mounting and

operating instructions.

Application area

The AG4000W air curtain unit is intended
for installation above entrances and doors
from 2 metres up to 4 metres in height. The
efficiency of the air curtain(s) depends on the
air temperature, pressure differences across
the doorway and any wind pressure.

AG4000W is intended for connection to a

water heating system.

AG4000 is installed above the entrance.
Protection class IP23.

Operation

Air is drawn in at the front side of the unit
and blown out downwards towards the
entrance so that it shields the door opening
and minimizes heat loss. To get the best
curtain effect the unit must extend the full
width of the door opening.

The grille for directing supply air is

adjustable and is normally angled outwards to
achieve the best protection against incoming
cold air.

The airflow can be adjusted by use of the fan

speed selector.

The efficiency of the air curtain(s) depends

on the air temperature, pressure differences
across the doorway and any wind pressure.

NOTE! Negative pressure in the building

considerably reduces the efficiency of the air
curtain. The ventilation should therefore be
balanced!

Installation

The unit is installed horizontally with the
supply air grille downwards as close to the
door as possible, preferably against the wall


and immediately above the doorway. For the
protection of wider doorways, several units
can be mounted next to each other. Ensure
that the service hatch is accessible and can be
fully opened.

The unit has 4 (6 on 2 and 2,5 meter

models) M10 fixed nuts on the upper side for
ceiling installation using threaded bars, or for
installation using wall brackets (accessories).
See dimension diagrams pages 2-3.

Electrical installation

Electrical connection may only be carried
out by an authorized electrician, and in
accordance with these instructions and the
applicable regulations.

1. The service hatch is opened by slackening

off the screws on the underside of the unit
as illustrated on page 3.

2. The unit is connected via one of the cable

glands in the upper side of the unit.


Different combinations for controlling fan
speed are available. See wiring diagrams
(pages 5-9).

Water coil connection

The water coil has copper tubes with
aluminium fins and is suitable for connection
to a closed water heating system. The heating
coil must not be connected to a mains
pressure water system or an open water
system.

The water pipes are connected to the

terminals on the upper side of the unit, see
page 2. Use a wrench or similar to hold the air
curtain connections to prevent straining the
pipes and subsequent water leakage during
connection to water supply pipe-work.

The connections to the heating coil must be

equipped with shut off valves to allow problem
free removal. The highest point of the pipes
supplying the unit with water must also be
fitted with a bleed valve. The installation must
be carried out by an authorised installer.

Mounting and operating instructions
