1. GENERAL FEATURES

Remove the appliance from the packaging, turn upside down and rest on the polystyrene.
Check that neither the appliance nor the power cable has been damaged in any way during transpor-
tation. Do not operate the appliance if damaged

2. FITTING THE FEET

Remove the feet and the castors.  Fit the castors to the spindles on the feet and push firmly until they
 click into position (fig. 1). Pull each castor to check that it is fitted correctly. In certain models, the


 are already mounted on the feet. Using the threaded u-bolt and wing nuts,

castors

fit the feet  to the

 bottom of the radiator between the last two elements as shown in figures 2, 3 and 4.
Depending on the type supplied, type A or type B, mount the feet as shown in figure 5 or 6.

Models with “Easy wheel” sytem

Turn the radiator upside-down on a rug or a soft surface in order to prevent damaging the paint fini-
sh. Fully unfold the castors by turning them outwards (Fig.7).
Turn the radiator back to its upright position.
IMPORTANT
When in use, the radiator should always be kept vertical (wheels at the bottom, controls at the top).
Any other position could be dangerous!

3. ELECTRICAL CONNECTION

-

Before plugging the radiator into the mains, check that the voltage of your mains electricity supply
corresponds  to  the  value  V  indicated  on  the  appliance  and  that  the  socket  and  power  line  are
appropriately dimensioned.

-

CONNECT THE RADIATOR TO EFFICIENTLY EARTHED SOCKETS ONLY

-

This appliance complies with EEC Directive 89/336 and D.M. 476/92, relating to electromagne-
tic compatibility.

4. INSTRUCTIONS FOR USE

Switching on
Plug  into  the  mains  socket.  Turn  the  thermostat  to  maximum.  Switch  the  radiator  on  using  the
switch/switches following the procedures given in points a) - b).

a) Models with single switch (1 power level):

-

button in position  «I» = Total power on (indicator light on);

-

button in position «O» = (indicator light off)

b) Models with double switch (3 power levels)

-

button in position «l» = minimum power (indicator light on);

-

button in position  «ll» = intermediate power (indicator light on);

-

both buttons in position «l » «ll » = maximum power (indicator lights on)

To turn appliance off, switch off both switches or remove plug from wall socket.

Adjusting the thermostat

When the room has reached the required temperature, turn the thermostat slowly anticlockwise until
the indicator light goes out (or until you hear a "click") and no further. The set temperature will then be
regulated automatically and kept constant by the thermostat.
Frost protection function
With the thermostat in position     and the switches pressed, the appliance maintains the room at a
temperature of about 5

C, preventing freezing with minimum energy consumption.

c) Models with a 24 hour time-clock (fig. 8)

To programme heating, proceed as follows:
-

Look at the time on your clock or watch. If it is 10.00, turn the numbered timer disk clockwise until
the number 10 on the disk coincides with the pointer

on the timer. Set the periods of time when

you want the appliance to work by pushing the teeth inwards. Each tooth corresponds to a period

3

GB
