– 3

Illustration



Screw the hose connection onto the
pump and make sure that the flat seal is
installed in the hose connection.

Note

The shorter the hose, the higher the feed
rate.



Push the hose on the hose connection
and fasten it with appropriate hose clip



In automatic mode, the switching height
is already predefined by the length of
the level sensor cable.

Illustration



In manual operations mode, align the
level sensor upward (cable pointing
downward). Tip: Push the cable of the
level sensor like a loop through the han-
dle and position the level sensor as
shown.

Illustration



Place the pump on a level, stabile sur-
face in the liquid to be transported, en-
sure that it is standing firmly or immerse
it using a rope tied to the handle.
The suction area should not be blocked
fully or partially through the impurities.

The fluid level must be at least 3 cm (SCP
5000) or 8 cm (SCDP 5000) for the pump to
suck in automatically.



Insert the mains plug into the socket.

In the automatic mode, the level switch au-
tomatically controls the pumping opera-
tions. The pump starts when the fluid level
reaches a certain height.
The pump is shut off starts when the fluid
level falls to a certain level.
Ensure that the level sensor is not obstruct-
ed in any way.

In manual opertions the pump remains
switched on continuously.

Note:

Dry run leads to increased wear and tear;
do not leave the pump unattended when it
is running. Switch off the pump within 3
minutes of dry running

.



Rinse the pump with clean water after
use.
Especially after running chlorinated wa-
ter or other liquids that leave residue
behind.

Note

Contaminations can accumulate and lead
to malfunctions.



Disconnect the main plug from the
socket.

The appliance is maintenance-free.

Preparing the Appliance

Operation

Automatic operation

Manual operation

Finish operation

Maintenance and Care

Maintenance
