Original instructions for use

467 773_a

11

ORIGINAL INSTRUCTIONS FOR USE

Contents

About  this  handbook........................................ 11
Product  description.......................................... 11
Scope  of  supply............................................... 12
Safety  instructions............................................ 12
Assembly.......................................................... 12
Startup.............................................................. 13
Maintenance  and  care..................................... 13
Storage............................................................. 14
Disposal............................................................ 14
Help in case of malfunction..............................14
Warranty........................................................... 15
EU declaration of conformity............................ 16

ABOUT THIS HANDBOOK

Read  this  documentation  before  starting  up

the  machine.  This  is  a  precondition  for  safe

working and flawless operation.
Observe  the  safety  warnings  in  this  docu-

mentation and on the product.
This  documentation  is  a  permanent  integral

part  of  the  product  described  and  must  be

passed on to the new owner if the product is

sold.

Explanation of symbols

CAUTION!

Following  these  safety  warnings  care-

fully  can  prevent  personal  injury  and/or

material damage.

ADVICE

Special  instructions  for  greater  ease  of

understanding and improved handling.

PRODUCT DESCRIPTION

Various different models of garden pumps are de-

scribed in this documentation. Identify your model

using the identification plate.

Product overview

see Fig. A, B

1 Pump inlet/suction line connection

2 Pump outlet/pressure line connection
3 Motor housing
4 Connection cable
5 On/off switch
6 Pump foot
7 Pump housing
8 Filling screw
9 Pump housing drain screw

10 Pressure line

11 Elbow nipple

12 Seal
13 Connecting nipple
14 Seal
15 Remove filter
16 Suction line

Function

The garden pump draws the water via the suction

line and feeds it to the pump outlet. It is operated

using an on/off switch.

Inox stainless steel

Units  marked  with  the  designation  "INOX"  are

supplied in stainless steel. The structure and func-

tion are unaffected by this.

Designated use

The  garden  pump  is  intended  for  private  use  in

house  and  garden.  It  must  only  be  used  in  the

framework of the deployment limitations in accor-

dance with the technical data.
The garden pump is suitable for:

Watering and irrigating
Re-pumping and pumping out of vessels (e.g.

swimming pools)
Water  extraction  from  streams,  rainwater

butts and cisterns.

The  garden  pump  is  is  suited  exclusively  for  the

conveying of the following fluids:

Clear water, rainwater
water  containing  chlorine  (e.g.  swimming

pools)
