Contents

About  this  handbook........................................ 15
Product  description.......................................... 15
Scope  of  delivery............................................. 16
Safety  instructions............................................ 16
Assembly.......................................................... 17
Startup.............................................................. 17
Maintenance  and  care..................................... 18
Storage............................................................. 19
Display  indications........................................... 19
Troubleshooting................................................ 22
Pressure  Switch............................................... 23
Disposal............................................................ 23
Warranty........................................................... 23
EU declaration of conformity............................ 23

ABOUT THIS HANDBOOK

Read  this  documentation  before  starting  up

the  machine.  This  is  a  precondition  for  safe

working and flawless operation.
Observe  the  safety  warnings  in  this  docu-

mentation and on the product.
This  documentation  is  a  permanent  integral

part  of  the  product  described  and  must  be

passed on to the new owner if the product is

sold.

Explanation of symbols

CAUTION!

Following  these  safety  warnings  care-

fully  can  prevent  personal  injury  and/or

material damage.

ADVICE

Special  instructions  for  greater  ease  of

understanding and improved handling.

PRODUCT DESCRIPTION

This  documentation  describes  several  different

models of house water systems. Identify your mo-

del using the identification plate.

Product overview

House water system (Fig. A - E)

1 Clear filter cover
2 Pump housing
3 Filling screw
4 Pump outlet/pressure line connection
5 Motor housing
6 Storage vessel
7 Screw-on point
8 Drain screw pump chamber
9 Drain screws filter chamber

10 Pump inlet/suction line connection

11 Pressure line

12 Water cock
13 Angle nipple
14 Seal
15 Connection nipple
16 Seal
17 Suction line
18 Filter spanner
19 Filter seal
20 Filter
21 Check valve
22 Seal non-return valve
23 Housing seal
24 Screw-in nipple
25 Seal
26 Measuring unit float body
27 Valve closing cover
28 Valve
29 Display
30 MODE button
