13

Note: Safety instruction booklet LS-123456 is supplied with the appliance.

Before using your appliance for the first time, read the booklet carefully and keep
it in a safe place.

DESCRIPTION

A

  Removable mincer head

 A1

  Aluminium casing

 A2

 Screw

 A3

   Self-sharpening stainless steel

blade

 A4

  Grilles (depending on model)

   A4a

   Small-hole grille (very fine

mincing)

   A4b

   Medium-hole grille (fine

mincing)

   A4c

   Large-hole grille (coarse

mincing)

 A5

  Aluminium nut

B

  Removable tray

C

  Meat pusher

D

  On/off button

E

   «Reverse» button (short reverse

movement)

F

  Mincer head release button

G

  Motor unit

H

 Accessory storage cover

I

   Sausage accessory (depending on

model)

J

   Kebbe accessory (depending on

model)

 J1

  Die end piece

 J2

 Ring

K

   Biscuit maker accessory (depending

on model)

 K1

 Support

 K2

 Mould

L

   Vegetable chopper (depending on

model)

 L1

  Drum body/feed tube

 L2

 Pusher

 L3

  Drums (depending on model)

   L3a

 Slicing drum

   L3b

 Coarse grating drum

   L3c

 Fine grating drum

   L3d

 Scraper drum

   L3e

 Ice shaving drum

USE

Before using for the first time, wash all the accessories in soapy water. Rinse and
dr y them carefully.
The grille and the blade should be lightly greased. Coat them with oil.
•  Do not operate your appliance while it is empty if the grilles have not been greased.
• Never push down into the tubes using your fingers or any utensil.

Note: Handle the drums with caution as they are very sharp.

USE Meat grinder head (fig. 1.1 to 2.4)

Prepare the entire quantity of food to be minced, remove any bones, gristle and
tendons. Cut the meat into pieces.

(approx. 2 cm x 2 cm)

Tip: At the end of operation, you can pass a few pieces of bread through the

grinder in order to extract all the ground meat.

EN
