Instruction manual

Bluetooth operation

•

The Bluetooth pairing name of the unit is
TF-PS2201.

•

Press the SOURCE button on the top
panel to switch to the Bluetooth mode.

•

Use your mobile phone to search the
Bluetooth signal of the unit, then input the
password 0000 if necessary. The units
are paired when

"bt"

 appears on the

screen.

•

Switch off the Bluetooth function on your
mobile phone to disconnect the units.
When paired successfully for the first
time, this unit will automatically connect
the paired device when it switches on.

•

Effective connection range is 10
meters.

•

•

You can unpair the devices by
deleting the TF-PS2201 Bluetooth
connection from your mobile phone
connected devices list or by
pressing and holding the PLAY/
PAUSE button in Bluetooth mode.
In Bluetooth mode you can control
playback and volume using the
standard control elements of this
unit.

•

You can insert a microphone for karaoke
or other purposes into this unit by
connecting it to the Microphone input.

•

While connected, you can control the
microphone volume and echo effect by
rotating the corresponding knobs.

Microphone

USB/SD operation

USB/SD playback

•

Insert a USB drive/SD CARD in the

corresponding USB port / SD card slot, the unit
will switch automatically to USB/SD CARD play
mode .

Playback operations

• During playback press the PLAY/PAUSE

button on the unit to pause playback. Press
this button again to resume playback.

• During playback press PREVIOUS/NEXT

buttons to go to a previous or a next track.

General USB/SD notes

• This unit is equipped with a USB port

that can read and play MP3 files stored on
standard USB flash drives (compatible with
USB version 2.0) up to 32 GB.

• This unit is also equipped with an SD

card socket that can accept and play MP3 files
stored on standard SD cards up to 32 GB.

  Always switch off the unit or change

mode to another one before removing a USB
flash drive or SD card, to prevent damage to
your USB device or memory card.

Note:

 Although this product is fully

compatible with USB 2.0 and SD card standard
formats, a small percentage of USB flash drives
and SD cards might not be readable, due to
those device manufacturers’ non-compliance
with the full (official) USB and SD card
standards.

• FAT and FAT32 file system are

supported by USB and SD ports of this unit.

           According to the USB 1.1/2.0 standard,
usage of a USB device with power current
consumption exceeding 500 mA is not
recommended without supplementary power
supply. Failure to use supplementary power
for connected USB drives with power
consumption exceeding this value as well as
defective
USB drives may cause mechanical or thermal
changes of elements of this unit as well as
failure of internal elements of the USB port.
Such damages are not warranty cases.

Warning

: use of external USB drives

containing BIN files in root directory may
cause malfunction of unit or damage to the
software.
