Instruction manual

Bluetooth operation

•

The Bluetooth pairing name of the unit is
TF-MS2102.

•

Press the SOURCE button on the top
panel to switch to the corresponding
signal source.

•

Alternatively you can press the Bluetooth
button to directly switch to the Bluetooth
mode.

•

Use your mobile phone to search the
Bluetooth signal of the unit, then input the
password 0000 if necessary. The units
are paired when the message "bt" is lit.

•

Switch off the Bluetooth function on your
mobile phone to disconnect the units.
When paired successfully for the first
time, this unit will automatically connect
the paired device when it switches on.

•

Effective connection range is 10
meters.

•

You can unpair the devices by
deleting the TF-MS2102 Bluetooth
connection from your mobile phone
connected devices list.

•

In Bluetooth mode you can control
playback and volume using the
standard control elements of this
unit.

•

Enable the Bluetooth function on your
mobile device and make sure it is in
searching mode.

•

Select "TF-MS2102" from the list of
discovered devices and connect to it.

•

The host speaker will act as the left
channel during TWS and will receive the
Bluetooth signal, the slave speaker will
act as the right channel to play music.

•

Press and hold the TWS button to
disconnect the HOST/SLAVE speaker
connection in the TWS mode.

TWS connection

•

The TWS (True Wireless Stereo)
Bluetooth connection can only be used
between the same two speakers.

•

Power on both speakers, press and hold
the TWS button on both speakers
simultaneously, the both speakers will
display PARTY SELECT on the display
screens.

•

Press the NEXT/PREVIOUS buttons to
select between HOST and SLAVE, wait a
few seconds to pair automatically, once
connected successfully, HOST will
appear on the display of the speaker
which is selected as the host, while the
other display will show SLAVE on the
display.

•

You can insert a microphone for
karaoke or other purposes into this
unit by connecting it to the
Microphone input.

•

While connected, you can control
the microphone volume and echo
effect by rotating the corresponding
knobs.

Microphone

•

You can connect a guitar to this
unit by connecting it using a
special 6.5 mm cable to the
Guitar input.

•

While connected, you can
control the guitar volume by
rotating the corresponding knob.

Guitar
