Instruction manual

Utilization of the product

If you want to dispose this product, do not

mix it with general household waste. There is a
separate collection system for used electronic
products in accordance with legislation that
requires proper treatment, recovery and
recycling.

Please contact your local authorities for

the correct method of disposal. By doing so,
you will ensure that your disposed product
undergoes the necessary treatment, recovery
and recycling and thus prevent potential
negative effects on the environment and
human health.

Important safeguards

• The instruction manual contains important

operating and maintenance instructions. For
your safety, it is necessary to refer the manual.
Keep the manual for use in future.

• Do not hit or drop the unit.
• Do not expose the unit to vibration, direct

sunlight, too high or low temperature or humidity.

• Do not disassemble the unit yourself.

Refer servicing to qualified service personnel.

Power supply

• Before the first connecting of the appliance

check that voltage indicated on the rating label
corresponds the mains voltage in your home.

• Insert the plug into power supply.

Caution:

 Always unplug the appliance from

power supply, when no use long time.

General operations

Power on/off

When the unit is connected to the current
supply mains, press and hold the
POWER button for 2 seconds to switch
the unit on. Press this button again to
switch the unit off.

L

ine input/Audio input

You can connect the audio output of an

external device to this unit, to listen to the sound
of that device through the speakers of this unit.

• To connect an external audio device,

please use a standard audio cable with 3.5-
mm-to-3.5 mm plugs to connect the input
terminal LINE IN/AUDIO IN (RCA L and R
inputs) on the unit.
Press SOURCE button on the unit to
switch to LINE IN/AUDIO IN mode. The
display screen will show "LINE/AUDIO".

• Turn on the external device. You cannot

control playback with the buttons of this unit
except adjusting the volume.

Volume

 control

Rotate the master volume knob to adjust the

general volume level of the unit.

You can also separately adjust the volume of

microphone (if connected), guitar (if
connected) and the echo effect by rotating the
corresponding knobs.

Equalizer

Press EQ button repeatedly to select an

equalizer mode.

Modes

Press the SOURCE button repeatedly to

select an operation mode: Bluetooth => USB
=> RADIO => LINE IN => AUDIO IN. The USB
mode is available only if a USB storage device
is connected.

LED indicator light

Press repeatedly the LIGHT button to switch

between various lighting modes of the LED
indicator light.

Audio output

Use a standard RCA audio cable plugs to

connect the L and R audio outputs (Party
speaker outputs) to the corresponding audio
inputs of an external media device (CD, DVD,
VCR, VCD, etc.).
