Preparing media

Disc

1

Press [

x

] to open the disc tray.

Put in a disc with the label facing up.
Press again to close the disc tray.

2

Press [SELECT <, >] repeatedly to select “CD”.

USB

Preparation

Before you connect a USB device to the system, make
sure you do a backup of the data.

1

Decrease the volume and connect the USB device
to the USB port.

Hold the main unit when connecting or disconnecting
the USB device.

2

Press [SELECT <, >] repeatedly to select “USB A”
or “USB B”.

USB status indicator lights up in red when selected.

Note:

• Do not use a USB extension cable. The system cannot

recognise USB device connected through a cable.

• Some devices cannot be charged as the maximum USB

charging current is 0.5 A only.

Bluetooth

®

You can connect and play an audio device wirelessly
through Bluetooth

®

.

Preparation

• Switch on the main unit.
• Switch on the Bluetooth

®

 feature of the device and put

the device near the system.

• Read the operating instructions of the device for details.

█

Pairing a device

Preparation

If this system is connected to a Bluetooth

®

 device,

disconnect it (

~

7).

1

Press [

].

If “PAIRING” is shown, continue with step 3.

2

Press [PLAY MENU] to select “PAIRING” and then
press [OK].

3

Select “SC-AKX320” from the Bluetooth

®

 menu of

the device.

If prompted for a passkey, input “0000” or “1234”.
The device connects with this system automatically
after pairing is complete.
The MAC address (example: 6C:5A:B5:B3:1D:0F)
may be shown before “SC-AKX320” is shown.
The name of the connected device is shown for a few
seconds.

Using the main unit

1

Press and hold [

] until “PAIRING” is shown.

2

Select “SC-AKX320” from the Bluetooth

®

 menu of

the device.

Note:

• You can pair up to 8 devices with this system. If a 9th device

is paired, the device that has not been used for the longest
time will be replaced.

• Depending on the searching functionality of the Bluetooth

®

device and the surrounding environment, if the product
name is not shown on the Bluetooth

®

 menu of the device,

switch off and then switch on the Bluetooth

®

 feature of the

device repeatedly during the pairing process.

█

Connecting a device

Preparation

If this system is connected to a Bluetooth

®

 device,

disconnect it (

~

7).

1

Press [

].

“BLUETOOTH READY” is shown.

2

Select “SC-AKX320” from the Bluetooth

®

 menu of

the device.

The name of the connected device is shown for a few
seconds.

3

Start playback on the device.

Note:

• A device must be paired to connect.
• This system can only connect to one device at a time.
• When “BLUETOOTH” is selected as the source, this system

will automatically try to connect to the last connected device.
(“LINKING” is shown during this process.)

█

Disconnecting a device

While a Bluetooth

®

 device is connected

1

Press [PLAY MENU] repeatedly to select
“DISCONNECT?”.

2

Press [

R

,

T

] to select “OK? YES” and then press

[OK].

“BLUETOOTH READY” is shown.
To cancel, select “OK? NO”.

Using the main unit

Press and hold [

] until “PAIRING” is shown.

Note:

A device is disconnected when you:
• Select a different source.
• Move the device out of the maximum range.
• Disable the Bluetooth

®

 transmission of the device.

• Switch off the system or the device.
