9

hFE-Transistor measurement

•  Remove the measuring cable.
•  Set the switch on the hFE setting.
•  Find out whether this transistor is a NPN or PNP transis-

tor and connect the Emitter- (e), Basic (b) and collector-
(c) cable to the appropriate socket in the switch gear
panel on the front side.

•  The display shows the (approximate) hFE value for a

basic current of 10 μA, V CE 2.8 V.

Measuring alternating current (AAC)

•  Connect the BLACK lead to the COM connector socket.

Connect the RED lead to the «VΩmA» connector socket.
For measurements between 200 mA and 10 A, remove
RED lead to «10 A» connector socket.

•  Set the FUNCTION switch on the desired «A~» setting

and connect the leads in series to the power circuit to
be measured. The polarity of the measuring tips is not
relevant.

• Read off  the value in (milli-) Ampere.

RANGE

ACCURACY

RES.

2 mA

± 1,2% of rdg ± 3 dgt

1 μA

20 mA

10 μA

200 mA

± 2% of rdg ± 3 dgt

100 μA

10 A

± 3% of rdg ± 7 dgt

10 mA

Overload protection 0.5 A / 250-V cut-out, 10 A-range not
protected. Frequency range: 40-1000 Hz. Display: Corrected
centre point (corresponds to the eff ective value in a sinusoi-
dal form.)

HINT:
•  In case the current range is previously unknown, you

must set the FUNCTION switch in the highest measure-
ment range and then reduce the measurement range
gradually if required.

•  If the fi gure «I» now appears on the display, the meas-

urand lies outside the range set. The FUNCTION switch
must be switched to a higher measurement range.

•  The 10 A range is not protected with a fuse. Do not,

therefore, measure for longer than 10 seconds.

Continuity test

•  Connect the BLACK lead to the «COM» connector socket

and the RED lead to the «VΩmA» connector socket.
(Hint: The polarity of the red lead is then «+».)

•  Set the FUNCTION switch on the «

 » range and

connectthe measuring tips to the power circuit to be
measured.

•  If the resistance in the power circuit is lower than 50 Ω,

the buzzer sounds.

Replacing the fuse

•  Set the switch on the OFF setting.
•  Remove the rear panel of the multimeter by loosening

the screws.

•  Remove the defective fuse and replace it with a fuse

of the same amperage and tripping characteristics
(250V~F500mAL).

CAUTION!

 The device must be switched off  and the leads

removed before opening the casing of the multimeter.

Changing battery

•  A battery symbol appears on the display if the battery is

almost discharged.

•  Set the rotary knob on the OFF setting.
•  Remove the rear panel of the multimeter by loosening

the screws.

•  Replace the 1 x 9 Volt battery by 1 x 6F229Volt.

CAUTION!

 The device must be switched off  and the leads

removed before opening the casing of the multimeter.

MAINTENANCE AND CLEANING

Always remove the battery before servicing and
cleaning of the multimeter. Never use water or
other fl uids to clean the device.

•  Keep the instrument leads and the multimeter clean.

Some cleaning media and solvents (petrol, thinner
etc.) can attach or dissolve the plastic. These products
contain benzol, trichloroethane, chlorine, aqueous am-
monia etc.

•  Clean the casing regularly using a soft piece of cloth,

preferably after every use.

•  Remove the stubborn dirt using moist cloth. Do not use

any solvents such as petrol, alcohol, ammoniac solution
etc. Such substances damage the plastic parts.

DISPOSAL

Discarded electric appliances are recyclable and
should not be discarded in the domestic waste!
Please actively support us in conserving resources
and protecting the environment by returning this

appliance to the collection centres (if available).
In order to prevent the machine from damage during
transport, it is delivered in a sturdy packaging. Most of
the packaging materials can be recycled. Take these ma-
terials to the appropriate recycling locations. Take your
unwanted machines to your local BORT GLOBAL LIMITED
dealer. Here they will be disposed of in an environmentally
safe way.
