EN

2 in 1: Portable Power

Cleaner/Water Sprayer

15

OPERATING INSTRUCTIONS

NOTE:

Before using the tool, read the

instruction book carefully.

INTENDED USE

This tool is intended for cleaning and watering.

ASSEMBLY & OPERATION

ACTION

FIGURE

BEFORE OPERATION

Installing the battery pack

See Fig. A1

Removing the battery pack

See Fig. A2

Checking the battery condition

See Fig. A3

Charging the battery pack

More details can be found in charger’s

manual

See Fig. A4

ASSEMBLY

NOTE:

The power nozzle has two

working modes: short lance only and

short lance used together with

extension lance.

Working mode 1

Attaching short lance to the power nozzle

NOTE:

When attaching, align the

two projections on the lance with the

grooves of the power nozzle as shown

in Fig. B.

See Fig. B

Attaching the Multi-spray nozzle

NOTE:

When attaching, rotate the

nozzle left and right to make sure the

nozzle fully seated into position and

gently pulling it to make sure it is

locked into position securely.

See Fig. C

Working mode 2

Attaching extension lance to the power

nozzle

Attaching short lance to the extension

lance

NOTE:

When attaching, align the

two projections on the lance with the

grooves of the power nozzle as shown

in Fig. D, E.

See Fig.

D, E

Attaching the hose to the power nozzle

NOTE:

 After the hose is attached, check

the connection by gently pulling upon

the hose. It should not be pulled off.

See Fig.

F1, F2

Attaching your own water hose

(optional)

1. Remove the hose adapter

2. Attach the home garden hose with

suitable connectors

NOTE:

Besides the hose supplied, you

can also connect the power nozzle to

your own water hose with suitable

connectors.

NOTE:

Check whether the filter screen

is missing before retightening the hose

adapter. When retightening the quick

hose adapter, please tighten securely.

Otherwise, it may not draw any water

for proper operation.

See Fig.

G1, G2, G3

OPERATION

WARNING: The supplied

battery is not waterproof. To

avoid risk of battery failure,

protect the battery from water

exposure during use. Store the

tool and battery in a dry place

after use.

Pressure setting

Your power nozzle has two pressure

modes. High pressure mode is

suitable for removing strong stains,

while low pressure mode applies

to light duty and watering.

See Fig. H

Start

NOTE:

At the first use, you need to

empty the air in hose, place the

power nozzle below waist level

(<1.5m/5ft) and set it at high pressure.

Do not start working until the water

goes up along the hose and

sprays out. This could take up to 30

seconds or more depending on

the fresh water source.

See Fig. I

Selecting the nozzle pattern

NOTE:

Choose a suitable nozzle pattern

according to your work. Spray

patterns 0

o

, 15

o

, 25

o

 and 40

o

 are

applicable for cleaning, and the spray

pattern with the symbol   is best

suitable for watering.

WARNING:

Do not shift the

nozzle pattern when the tool is

powered on.

See Fig. J

Cleaning

WARNING: Do not connect the

machine to water supplies that

are dirty, rusty, muddy, or

corrosive. (Including window

cleaning liquids, plant foods, or

fertilizers etc.)

NOTE:

 For proper maintenance after

using with sea water, the product

should be rinsed by fresh water.

See Fig.

K, L
