19

GB

USAGE

WARNING:

First of all read the

General Sec-

tion

 and then this

Specific Manual.

>

PUT INTO SERVICE

  See fig.

A

>

STARTING UP

  See fig.

B

>

HIGH PRESSURE LANCE

  See fig.

D

>

DETERGENT SUCTION

  See fig.

E

>

HIGH PRESSURE HOSE

  See fig.

F

>

WATER SUPPLY

Water supply collection

WARNING (symbol):

 machine not suitable

for connection to the potable water mains.

The cleaner can only be connected to the

water mains if the water mains is separated by

a backflow preventer.

Make sure that the hose is at least Ø 13mm-1/2

inch and that it is reinforced.

WARNING:

Water that has flown through

backflow preventers is considered to be non-

potable.

EFCO IP 1150 S

OLEO-MAC PW 115 C

ELECTRICAL CONNECTION

Mains power supply

220 - 240 V   -   1 ~ 50/60 Hz

Absorbed power

1,75 kW

Fuse

16 A

HYDRAULIC CONNECTION

Maximum inlet water temperature

40 °C   -   98 °F

Minimum inlet water temperature

5 °C   -   41 °F

Minimum inlet water flow

900 l/h   -   15 l/min   -   172 US gph

Maximum inlet water pressure

1 MPa   -   10 bar   -   145 psi

Minimum inlet water pressure

0,1 MPa   -   1 bar   -   14,5 psi

PERFORMANCE

Water flow

360 l/h   -   6 l/min   -   95 US gph

Maximum pressure

12,5 MPa   -   125 bar   -   1813 psi

Recoil of cleaner gun

10 N

Sound pressure level - Uncertainty (*)

81 dB(A)   -   0,7 dB(A)

Sound power level

96 dB(A)

Operator arm vibrations - Uncertainty (*)

1,5 m/s²   -   0,5 m/ s²

WEIGHT AND DIMENSION

Lenght x width x height

310 x 280 x 650 mm   -   12,2 x 11 x 25,6 in

Weight

7 kg   -   15,4 lb

Detergent bottle capacity

0,7 l   -   0,18 US gal

(*) Measurements taken in compliance with EN 60335-2-79
All features and technical specifications are only indications. The Manufacturer reserves the right to modify the appliance as it

deems necessary.

FEATURES AND TECHNICAL

SPECIFICATIONS
