– 8

ATTENTION

Risk of damage to the paintwork
When working with the washing brush, it must be free of
dirt or other particles.



Push the washing brush into the trigger gun and
fasten it by a 90° turn.

Note

: If required, the washing brushes can be used to

work with detergent.

*

 Optional accessories

Most KÄRCHER detergents can be bought ready to use
in a Plug 'n' Clean detergent bottle.

Note:

 Detergent can only be added when the device is

operated in low pressure mode.



DANGER

When using detergents, the material data safety sheet
issued by the detergent manufacturer must be adhered
to, especially the instructions regarding personal pro-
tective equipment.



Remove the cap of the Plug 'n' Clean detergent
bottle.

Illustration



Push the detergent bottle with the opening pointing
downwards into the connection for the Plug 'n'
Clean detergent.



Use Vario Power spray lance.



Turn the spray lance towards "MIX" until the the
LED "MIX" is on on the pressure indicator of the
trigger gun.

Note:

 This will mix the detergent with the water

stream.



Spray the detergent sparingly on the dry surface
and allow it to react, but not to dry.



Spray off loosened dirt with the high pressure jet.



Remove the Plug 'n' Clean detergent bottle from
the intake and close it with the lid.



For storage, put the detergent bottle into the retain-
er with the cap pointing up.



Fill the detergent solution in the detergent tank of
the foam nozzle (observe dosage instructions on
the packaging of the detergent).



Connect the detergent tank to the foam nozzle.



Connect the foam nozzle to the trigger gun.



Release the lever of the trigger gun.



Lock the lever of the trigger gun.

Illustration



Put the trigger gun with the spray lance into the
parking position.



During longer breaks (more than 5 minutes), also
turn the appliance off using the "0/OFF" switch.



Release the lever of the trigger gun.



Turn off the appliance "0/OFF".



Disconnect the mains plug from the socket.

몇

CAUTION

Only separate the high-pressure hose from the trigger
gun or the device when there is no pressure in the sys-
tem.



Turn off tap.



Press the lever of the trigger gun to release any re-
maining pressure in the system.



Release the lever of the trigger gun.



Lock the lever of the trigger gun.

ATTENTION

When disconnecting the supply or high pressure hose,
warm water may leak from the connections after opera-
tion.



Detach the appliance from the water supply.

몇

CAUTION

Risk of personal injury or damage!
Mind the weight of the appliance during transport.



Lift appliance by the carrying handle and carry it.



Pull out the transport handle until it audibly snaps
into place.



Pull the appliance by its transport handle.



Prior to horizontal transport: Remove the Plug 'n'
Clean detergent bottle from the intake and close it
with the lid.



Secure the appliance against shifting and tipping
over.

몇

CAUTION

Risk of personal injury or damage!
Consider the weight of the appliance when storing it.



Park the machine on an even surface.



Detach spray lance from the trigger gun.



Push the disconnect button on the trigger gun and
pull the high-pressure hose out of the trigger gun.



Place the trigger gun into the storage for the trigger
gun.



Put both spray lances into the storage for the spray
lance.

–

Dirtblaster spray lance: Nozzle towards the bottom.

–

Vario Power spray lance: Nozzle towards the top.



Coil the high-pressure hose and hang it over the
hose storage.



Store the mains connection in the accessory com-
partment.

Prior to extended storage periods, as during the winter,
also observe the instructions in the Care section.

Operation with washing brush

Operation with detergent

Recommended cleaning method

After operation with detergent

Foam nozzle

Interrupting operation

Finish operation

Transport

When transporting by hand

When transporting in vehicles

Storage

Storing the Appliance
