The scope of delivery of the device (depending on the
model) is illustrated on the packaging. These operating
instructions describe all possible options.

See fold-out page 4 for illustrations

1

Coupling element for water connection

2

Water connection with integrated sieve

3

High pressure hose

4

Hose guide

5

Storage for spray lances

6

Storage / parking position for trigger gun

7

Connection for Plug 'n' Clean detergent

8

Carrying handle

9

Transport handle, detachable

10 Hose holder
11 High pressure connection
12 Appliance switch „0/OFF“ / „I/ON“
13 Mains cable with mains plug
14 Nameplate
15 Accessory compartment
16 Hooks for fastening the net
17 Net for accessory compartment
18 Bearing wheel
19 Base with carrying handle
20 Full Control trigger gun
21 Battery compartment
22 LED pressure indicator

MIX / 1 - SOFT / 2 - MEDIUM / 3 - HARD

23 Battery compartment lock
24 Lock trigger gun
25 Button for detaching the high-pressure hose from

the trigger gun

26 Full Control spray lance Vario Power

Carrying out the most common cleaning tasks.
Pressure levels: HARD / MEDIUM / SOFT / MIX

27 Full Control spray lance Dirtblaster

For strong contaminations.
Pressure level: HARD

See fold-out page 3 for illustrations

Mount loose parts delivered with appliance prior to start-
up.
You will need the 2 included screws as well as a Philips
screwdriver PH 2.

Illustration



Secure the wheels using the included plug. Align
the plug properly!



Insert the cover and screw in.

Illustration



Insert base.



Insert the included dowels all the way into the
holes.



Secure the base with the enclosed screws.

Illustration



Hook in storage for spray lances.



Secure the storage for the spray lances by means
of two screws.

Illustration



Attach the transport handle.



Secure the transport handle by means of two
screws.

Illustration



Hook the net into the hooks shown in the illustra-
tion.



Completely wind off the high-pressure hose and
disentangle any loops and knots.

Illustration



Put the disentangled high-pressure hose through
the hose guide from the back.

Illustration



Push the high pressure hose into the trigger gun
until it locks audibly.

Note:

 Make sure the connection nipple is aligned

correctly.



Check the secure connection by pulling on the high
pressure hose.

Description of the Appliance

* Optional

28 Rotary washing brush

Especially suitable for cleaning cars.

29 Foam nozzle with detergent container

With powerful foam for effortless cleaning.

30 Plug 'n' Clean detergent bottle with locking lid

** Additionally required

31 Fabric-reinforced water hose with commercially

available coupling.

– Minimum diameter, 1/2 inches (13 mm).
– Minimum length 7.5 m.

Assembly

Install wheels

Installing the base

Install storage for spray lances

Install the transport handle

Attach the net to the accessory compartment

Winding off the high pressure hose

Putting the high pressure hose through the

hose guide.

Connect the high pressure hose to the

trigger gun
