16

English

Subject to technical modifications!

We hereby declare that the machine de-
scribed below complies with the relevant
basic safety and health requirements of the
EU Directives, both in its basic design and
construction as well as in the version put
into circulation by us. This declaration shall
cease to be valid if the machine is modified
without our prior approval.

The undersigned act on behalf and under
the power of attorney of the company man-
agement.

Alfred Kärcher GmbH Co. KG
Alfred Kärcher-Str. 28 - 40
D - 71364 Winnenden
Phone: +49 7195 14-0
Fax: +49 7195 14-2212

Technical specifications

Power connection

Voltage

230-240

1~50

V
Hz

Connected load

2,0 kW

Mains fuse (slow-blow)

10 A

Protective class

I

Protection class

IP X5

Water connection

Max. feed temperature

40 °C

Min. feed volume

10 I/min

Max. feed pressure

1,2 MPa

Performance data

Working pressure

12 MPa

Max. permissible pressure

14 MPa

Water flow rate

7,5 I/min

Detergent flow rate

0-0,4 I/min

Recoil force of trigger gun

21 N

Hand-arm vibration
(ISO 5349)

0,8 m/s

2

Sound pressure level
L

pA

 (EN60704-1)

82 dB(A)

Sound power level
L

WA

 (2000/14/EG)

97 dB(A)

Dimensions

Length

508 mm

Width

255 mm

Height

284 mm

Weight

13,4 kg

CE declaration

Product:

High-pressure cleaner

Type:

1.069-xxx

Relevant EU Directives

98/37/EC
2006/95/EC
2004/108/EC
2000/14/EC

Applied harmonized standards

EN 55014–1: 2006
EN 55014–2: 1997 + A1: 2001
EN 60335–1
EN 60335–2–79
EN 61000–3–2: 2000 + A2: 2005
EN 61000–3–3: 1995 + A1: 2001 + A2:
2005

Applied conformity evaluation method

Appendix V

Sound power level dB(A)

Measured:

95

Guaranteed:

97

CEO

Head of Approbation
