15

Connect a clean water supply pipe to the

water mains, checking to ensure that the

minimum pressure is of 1.5 bar and maxi-

mum is of 6 bar, with a minimum flow rate

of 7 l per min.

-  Connect the water supply pipe (min. diam ½”) to

the water mains (Fig.

2

)

-  Screw  the male connector (Fig.

3

) on to the at-

tachment of the water supply (

2

); snap the female

connector of the tube (

3

) on to the connector.

3

CONNECTION OF THE WATER SUPPLY PIPE

Based on the prescriptions and provisions

set forth by the regulations currently in

force, it is mandatory that the appliance

is never operated without a potable water

backflow  preventer  device,  connected  up  to  the

potable water supply mains. Use a suitable potable

water  backflow  preventer  device,  compliant  to  the

EN 12729 type BA standard provisions. Water that

flows through a system backflow preventer cannot

be classified as potable water.

4

HIGH PRESSURE PIPE CONNECTION

-  Unwind the pressure hose off the hose drum (Fig.

4

).

-  Screw  the high pressure tube on to the gun  (Fig.

5

).

5

ELECTRICAL CONNECTION OF THE AP-

PLIANCE

The mains voltage must match the operating volta-

ge. (See identification plate)

Insert the plug into a power socket  installed in

compliance with regulations.

Check the minimum section of the individual cables

using extensions.

Position the extensions so as to maintain the pro-

tection class of the equipment.

Voltage

Cable

Cross-section

    V                length m

      mm

2

   230

up to 2

       1,5

   230

20 to 5

       2,5

6 APPLIANCE ACTIVATION

Operate the equipment in vertical position

(Fig.

7

) only after connecting the water

supply pipe and turning on the tap.

-   Position the switch on

I

 (

ON

) (Fig.

8

).

-

Position the spray gun on the object to be

cleaned - never on people !

-  Press the safety device (Fig.

9

) - the gun is released

-  Direct the nozzle downwards (Fig.

7

)

-  Fully press down the trigger (Fig.

7

)

7

SWITCHING OFF THE MACHINE

-   Position the switch on

O

 (OFF) (Fig.

8

).

-  Turn off water supply tap.

-    Actuate spray gun until water drips from the

nozzle (machine is now de-pressurized).

-   Release trigger.

-   Press safety latch on spray gun. (Fig.

9

). The

spray gun is locked and cannot be actuated

accidentally.

-   Unplug machine from socket outlet.

-  Disconnect water supply hose from machine and

water supply mains.

8 ACCESSORIES

Variable nozzle

The nozzle (Fig.

10

) can be regulated in a conti-

nuous manner, by rotating the regulation bushing,

changing it from a pinhole jet (Fig.

10

) to a flat jet

and viceversa.

It can be used at either high or low pressure by

shifting the head in a longitudinal sense according to

the direction of the arrow on the head itself (Fig.

11

).

ADDITION OF DETERGENT

The detergents must not be allowed to

dry on the object to be cleaned.

The  product  is  fitted  with  one  detergent

tank.Fill the detergent tank (Fig.

12

) with detergent,

dilute as recommended.

Winder kit

The rotation sense for the winding of the high pres-

sure hose is only permitted in a clockwise direction.

(Fig.

13

).

9 MAINTENANCE , REPAIRS  AND STORAGE

Before undertaking any work

on the appliance always de-

tachthe plug from the power

socket

Undertake only the maintenance operations descri-

bed in the user instructions.
Contact the Technical Assistance service for all other

interventions.
Use only original spares.
Should the power cable be damaged, it must be

replaced by a cable or a set of special cables avai-

lable from the manufacturer or its assistance service.
The pins and joints of the connection cables of the

electrical system must be protected against accidental

water sprays.

Cleaning/inspecting the strainer

Expose  the strainer  (Fig.

14

) in the machine water
