6

use.

Figure 7 - Detergend application

UNITS WITH DETERGENT APPLICATOR

INCLUDED

Follow manufacturer’s label directions for mixing correct

concentrations of detergent to water ratio through the

pressure washer is approximately 5.4% (1 to 19).

1.  Unscrew to top of detergent applicator and fill applica

-

tor with detergent.

2. Replace top on applicator.

3. Remove lance from gun.

4. Attach detergent applicator to gun. ( See Figure 8)

Figure 8 - Attach applicator to gun

5. Apply detergent so it thoroughly covers cleaning sur-

face. Apply from bottom to top to prevent detergent from

sliding down and streaking.

6. Allow detergent to remain on the surface for a few min-

utes. This is a good time to use a brush to lightly scrub

heavily soiled areas.

Never allow detergent to dry on the cleaning surface.

7. Remove detergent applicator from gun and replace

with the lance, or remove applicator from end of lance.

8. Rinse detergent from surface.

NOTE:

 Flush detergent applicator with clear water fol-

lowing each use.

4. Final Rinse

Start  final  rinse  at  bottom  an  work  upward.  Make  sure

you thoroughly rinse the surface and that all detergent

has been removed.

5. Shut down

1. Be sure all detergent is flushed from system.

2. Turn off motor.

3. Turn off water supply.

4.  After motor and water supply are turned off, trigger gun

to depressurize system.

CAUTION:

  NEVER  turn  water  supply  off  before  turning

motor off. Serious damage could occur to the pump and

or motor.

WARNING!

 NEVER disconnect high pressure discharge

hose from machine while system is pressurized. To

depressurize,  turn  motor  off,  turn  water  supply  off  and

squeeze gun trigger 2-3 times.

5.  After each use, wipe all surfaces of the pressure wash-

er with a clean, damp cloth.

6. Storage

Do not store pressure washer outdoors.

Do not store pressure washer where it might freeze.

TIPS FOR EXTENDING THE LIFE

OF YOUR PRESSURE WASHER

1. Never operate unit without water.

2.  Pressure washer is not meant to pump hot water. Nev-

er  connect  to  hot  water  supply  –  this  will  significantly

reduce life of the pump.

3.  Using detergent other than others brand may cause

damage to pump components (o-rings, etc.).This also

applies to chemicals such as bleach, dish soap, etc.

4.  Never operate unit for more than one (1) minute with-

out spraying water. Resulting heat buildup will damage

pump.

5.  Before adjusting nozzle’s pressure (high-to-low or low-

to-high) release trigger. Failure to do so will reduce life

of o-rings in lance.

THE SUCTION FUNCTION

You can connect the high pressure cleaner to the water

sources such as taps or pump water from other sources

without pressure.

To work with the water supply without pressure the suc-

tion hose should be removed from the supply and the

gun nozzle should be moved to position “Low” (Figure

14). After that the high pressure cleaner should work idle

for a few seconds to drain the excess water and release

air.  Put the suction hose into the water source. After

draining some water the gun nozzle should be moved

to position “High” (Figure 14). Now the high pressure

cleaner is ready to work under high pressure.

TROUBLESHOOTING

1. When switched on, the machine will not start

working.

●  Plug is not well connected or electric socket is faulty.

  -  Check plug, socket and fuse.

●  The mains voltage is lower than the minimum require

-

ment for start up.

  Check that the mains voltage is adequate.

●  The pump is stuck.

  -  Refer  to  after  storage  instructions.  Switch  off  the

unit and let the motor cool.

●  Thermal safety has tripped.

  -  Leave the lance open with water comingthrough.

2.  Fluctuating pressure

●  Pump sucking air

  -  Check that hoses and connections are airtight

●  Valves dirty, worn out or stuck. Pump seals worn.

  -  Clean and replace or refer to dealer.

3.  Water leaking from the pump

●  Seals worn out

  -  Check and replace, or refer to dealer

4.  The motor stops suddenly

●  Thermal safety switch has tripped due to overheating.

  -  Check that the mains voltage corresponds to speci-

fications.  An  extension  cable,  which  is  too  thin,  and
