Remove all packing material and accessories.

Examine the oven for any damage such as

dents or broken door. Do not install if oven is

damaged.

Countertop Installation

Cabinet: Remove any protective film found

on the microwave oven cabinet surface.

Do not remove the light brown Mica cover

that  is attached  to  the  oven  cavity  to

protect the magnetron.

Installation

1.Select a level surface that

provide enough open space

for the intake and/or outlet

vents.

(1)  The minimum installation

height is 85cm.

(2)  The rear surface of

appliance shall be placed

against a wall.

Leave a minimum clearance

of 30cm above the oven, a

minimum clearance of 20cm

is required between the oven

and any adjacent walls.

(3)  Do not remove the legs

from the bottom of the oven.

(4) Blocking the intake and/

or outlet openings can

damage the oven.

(5) Place the oven as far

away from radios and TV

as possible. Operation of

microwave oven may

cause interference to your

radio or TV reception.

2. Plug your oven into a

standard household outlet.

Be sure the voltage and

the frequency is the same

as the voltage and the

frequency on the rating

label.
WARNING: Do not install

oven over a range cooktop

or other heat-producing

appliance. If installed near

or over a heat source, the

oven could be damaged

and the warranty would be

void.

The accessible
surface may be
hot during operation.

7-8cm

7-8cm

7-8cm

EN

-

11
