18

INSTALLATION

Turntable Installation

Turntable Installation

a. Never place the glass tray upside down. The

glass tray should never be restricted.

b. All food and containers of food are always

placed on the glass tray for cooking.

c. If glass tray cracks or breaks, contact your

nearest authorized service center.

Countertop Installation

Countertop Installation

Remove all packing material and accessories.

Examine the oven for any damage such as

dents or broken door. Do not install if oven is

damaged.

Cabinet: Remove any protective

fi

 lm found on

the microwave oven cabinet surface. Do not

remove the light brown Mica cover that is attached to the oven cavity to pro-

tect the magnetron.

INSTALLATION

INSTALLATION

1. Select a level surface that provide enough open space for the intake and/or

outlet vents.

A minimum clearance of 7.5cm is required between the oven and any adjacent

walls. One side must be open.

(1) Leave a minimum clearance of

30cm above the oven.

(2) Do not remove the legs from the

bottom of the oven.

(3) Blocking the intake and/or outlet

openings can damage the oven.

(4) Place the oven as far away from

radios and TV as possible.

Operation of microwave oven may

cause interference to your radio or

TV reception.

2. Plug your oven into a standard household outlet. Be sure the voltage and the

frequency is the same as the voltage and the frequency on the rating label.

WARNING: Do not install oven over a range cooktop or other heat-producing

appliance. If installed near or over a heat source, the oven could be damaged

and the warranty would be void.
