6. Thermometer

6.1 RF Transmission Procedure:

 •  The main unit automatically starts receiving transmission from outdoor thermo sensor



for outdoor temperature after batteries are inserted.

 •  The thermo sensor unit will automatically transmit temperature signal to the main unit



after batteries inserted.

 •  For having more than one external transmitter (Maximum3), select the Channel, CH1,



CH2 or CH3 to ensure each sensor is transmitting difference channel before inserting



batteries. The channel select switch (D3) is at the back of the thermo sensor.

 •  If main unit failed to receive transmission from outdoor thermo sensor in first 3 minutes



after the batteries inserted (“- - . –”display on the LCD), hold “Channel” button (B8) for



3 seconds to receive transmission manually. RF icon “

 ”   flashes on the LCD



Note: Buttons (except “Light” button (B2)) will not function while scanning for thermo



sensor’s signal unless they are well received or stopped manually.

6.2 Temperature

(1) Outdoor Temperature--- Channel Selection

 •  Press “CHANNEL” button (B8) to view the 3 Channels’ temperature. The sequence is



shown as follow:



PRESS “CHANNEL” button      >      PRESS “CHANNEL” button      >       PRESS “CHANNEL” button





 •  When viewing the record on CHANNEL 1 or 2, or 3, hold “CHANNEL” button (B8) for 3



seconds to cancel the record on this channel manually, and receive the transmission



from channels automatically again.

(2) Outdoor Temperature Trend

 •  The trend pointer (A5) displayed on the LCD indicates the trend of the outdoor



temperature.

(3) Celsius / Fahrenheit

 •  Press “°C /°F” button (B4) to select Indoor/Outdoor Temperature in Celsius mode or



Fahrenheit mode.

 •  If the temperature is out of the measurable range, LL.L (beyond the minimum



temperature) or HH.H (beyond the maximum temperature) will be shown on the LCD.

Display the three

channels alternatively

Indicating the outdoor

temp. is rising

Indicating the outdoor

temp. is steady

Indicating the outdoor

temp. is falling

ENGLISH   5

ENGLISH   6

4. Getting Started

4.1 Main Unit:

 •  Slide open main unit battery compartment cover [C2]
 •  Insert 3 x AAA batteries observing polarity [“ +” and “ –“ marks]
 •  Replace main unit battery compartment cover [C2]
 •  Use a pin to press the RESET [B9] button on the rear of the main unit, the main unit is


now ready for use

4.2 Outdoor Thermo Sensor

 •  Batteries compartment (D5) of thermo sensor is locating behind the back cover,


unscrews the batteries cover to open.

 •  Insert 2 x AAA batteries observing polarity [ “+” and “–“ marks]

5. Installation

5.1 Main Unit

The  main  unit  can  be  placed  onto  any  flat  surface  (C3),  or  wall  mounted  by  the  hanging
hole (C1) at the back of the unit.

5.2 Outdoor Thermo sensor

The remote sensor should be securely mounted onto a horizontal surface.

Note:

Transmissions  between  receiver  and  transmitter  can  reach  up  to  30m  in  open  area.

Open  Area:  there  are  no  interfering  obstacles  such  as  buildings,  trees,  vehicles,  high
voltage lines, etc.
