17

Continued from previous column

M.2 SSD Slots

∙

4x M.2 slots (Key M)
•  M2_1 slot (From CPU)

•  Supports up to PCIe 5.0 x4
•  Supports 2280/ 22110 storage devices

•  M2_2, M2_3 & M2_4 slots (From X670 chipset)

•  Supports up to PCIe 4.0 x4
•  Supports 2260/ 2280 storage devices

* PCI_E4 & M2_4 share the bandwidth. The PCI_E4 slot will be unavailable

when installing devices into the M2_4 slot.

RAID

∙

Supports RAID 0, RAID 1 and RAID 10 for SATA storage

devices*

∙

Supports RAID 0, RAID 1  and RAID 10 for M.2 NVMe

storage devices

* SATA_A1 & SATA_A2 do not support RAID function.

Audio

Realtek® ALC4080 Codec

∙

7.1-Channel High Definition Audio

∙

Supports S/PDIF output

LAN

1x Realtek 8125B 2.5Gbps LAN controllers

Wireless LAN &

Bluetooth®

AMD® Wi-Fi RZ616

∙

The Wireless module is pre-installed in the M.2 (Key-E)

slot

∙

Supports MU-MIMO TX/RX

∙

Supports 20MHz, 40MHz, 80MHz,160MHz bandwidth in

2.4GHz/ 5GHz or 6GHz* bands

∙

Supports 802.11a/ b/ g/ n/ ac/ ax

∙

Supports Bluetooth® 5.2**

* Wi-Fi 6E 6GHz may depend on every country’s regulations and will be ready in

Windows 10 21H1 and Windows 11.
** Bluetooth 5.2 will be ready in Windows 10 21H1 and Windows 11.

Power Connectors

∙

1x 24-pin ATX main power connector

∙

2x 8-pin EPS 12V power connectors

Continued on next column
