Hardware Installation

1-2  Product Specifications

  CPU



  Support for Intel

®

 Core

™

 i7 processors/Intel

®

 Core

™

 i5 processors/Intel

®

 Core

™

 i3

processors/Intel

®

 Pentium

®

 processors in the LGA1156 package

(Go to GIGABYTE's website for the latest CPU support list.)



  L3 cache varies with CPU

  Chipset

  

Intel

®

 H55 Express Chipset

  Memory



  2 x 1.5V DDR3 DIMM sockets supporting up to 16 GB of system memory

 (Note 1)



  Dual channel memory architecture



  Support for DDR3 1666 (O.C.)/1333/1066/800 MHz memory modules



  Support for non-ECC memory modules



  Support for Extreme Memory Profile (XMP) memory modules

(Go to GIGABYTE's website for the latest supported memory speeds and

memory modules.)

  Onboard Graphics



  Integrated in the Chipset:

- 1 x DVI-D port

(Note 2)(Note 3)

j

- 1 x D-Sub port

(Note 2)

  Audio

      

Realtek ALC888B codec



High Definition Audio



2/4/5.1/7.1-channel

(Note 4)

  LAN

  

1 x Realtek RTL8111E chip (10/100/1000 Mbit)

  Expansion Slots



  1 x PCI Express x16 slot, running at x16

(The PCIEX16 slot conforms to PCI Express 2.0 standard.)



  1 x PCI Express x1 slot



  2 x PCI slots

  Storage Interface



  Chipset:

-  6 x SATA 3Gb/s connectors supporting up to 6 SATA 3Gb/s devices

  USB



  Chipset:

-  Up to 12 USB 2.0/1.1 ports (8 on the back panel, 4 via the USB brackets

connected to the internal USB headers)

  Internal



  1 x 24-pin ATX main power connector

 Connectors



  1 x 4-pin ATX 12V power connector



  6 x SATA 3Gb/s connectors



  1 x CPU fan header



  1 x system fan header



  1 x front panel header



  1 x front panel audio header



  2 x USB 2.0/1.1 headers



  1 x serial port header

j



  1 x clearing CMOS jumper

j

  Only for GA-H55M-S2V.
