Appendix
- 67 -
English
Please follow the steps below to construct a complete RAID array:
1) Have ready your hard drives for RAID construction.
Note: To achieve best performance, it is recommended that the hard drives used are of similar make
and storage capacity.
2) Please attach the hard drive connectors to their appropriate location on the motherboard ie. IDE, SCSI,
or SATA.
3) Enter the motherboard BIOS and locate RAID setup (Please refer to the section on Integrated Peripherals).
4) Enter RAID setup in the BIOS and select the RAID type (For instance, enter Tab to select VT8237R
RAID; Ctrl + S to select Silicon Image).
5) Complete driver installation.
6) Complete RAID utility installation.
More information on steps 4 and 5 is provided. (For more detailed setup information, please visit our website
at http:\\www.gigabyte.com.tw to read or download the information you need.)
Configuring the VT8237(VT8237R) SATA RAID BIOS
The RAID BIOS setup utility lets you choose the RAID array type and which hard drives you want to make
part of the array.
Entering the VT8237(VT8237R) SATA RAID BIOS Setup Utility
1. After rebooting your computer, wait until you see the RAID software prompting you to press
Tab
. The
RAID prompt appears as part of the system POST and boot process prior to loading the OS. You have a few
seconds to press
Tab
before the window disappears.
Press
Tab
to enter RAID setup utility, the
VT8237 SATA RAID BIOS
utility screen will appear. You can press
up arrow key< > or down arrow key< > to move the selection bar and select the item that you want to
execute.
VIA Technologies, Inc. VIA VT8237 Serial ATA RAID BIOS Setting Utility V2.31
Copyright (C) VIA Technologies, Inc. All Right reserved.
Scan Devices, Please wait...
Press <Tab> key into User Window!
Serial_Ch0 Master : ST3120026AS
Serial_Ch1 Master : ST3120026AS
Create Array
Delete Array
Create/Delete Spare
Select Boot Array
Serial Number View
VIA Tech. VT8237 SATA RAID BIOS Ver 2.31
Channel
Drive Name
Array Name
Mode
Size(GB)
Status
Serial_Ch0 Master
ST3120026AS
SATA
111.79
Hdd
Serial_Ch1 Master
ST3120026AS
SATA
111.79
Hdd
Create a RAID array with
the hard disks attached to
VIA RAID controller
F1
: View Array/disk Status
,
: Move to next item
Enter : Confirm the selection
ESC
: Exit
