- 39 -
BIOS Setup
Date (mm:dd:yy)
Sets the system date. The date format is week (read-only), month, date and year. Select the desired field
and use the up arrow or down arrow key to set the date.
Time (hh:mm:ss)
Sets the system time. For example, 1 p.m. is 13:0:0. Select the desired field and use the up arrow or
down arrow key to set the time.
IDE Channel 2, 3 Master/Slave
IDE Auto-Detection
Press <Enter> to autodetect the parameters of the SATA device on this channel.
Extended IDE Drive
Configure your SATA devices by using one of the two methods below:
•
Auto
Lets the BIOS automatically detect SATA devices during the POST. (Default)
•
None
If no SATA devices are used, set this item to
None
so the system will skip
the detection of the device during the POST for faster system startup.
Access Mode
Sets the hard drive access mode. Options are: Auto (default), Large.
The following fields display your hard drive specifications. If you wish to enter the parameters manually,
refer to the information on the hard drive.
Capacity
Approximate capacity of the currently installed hard drive.
Halt On
Allows you to determine whether the system will stop for an error during the POST.
All Errors
Whenever the BIOS detects a non-fatal error the system boot will stop.
No Errors
The system boot will not stop for any error.
All, But Keyboard The system boot will not stop for a keyboard error but stop for all other errors.
(Default)
Memory
These fields are read-only and are determined by the BIOS POST.
Base Memory Also called conventional memory. Typically, 640 KB will be reserved for the
MS-DOS operating system.
Extended Memory The amount of extended memory.
2-4 Standard CMOS Features
CMOS Setup Utility-Copyright (C) 1984-2011 Award Software
Standard CMOS Features
Date (mm:dd:yy)
Tue,
Mar 15 2011
Time (hh:mm:ss)
22:31:24
IDE Channel 2 Master
[None]
IDE Channel 2 Slave
[None]
IDE Channel 3 Master
[None]
IDE Channel 3 Slave
[None]
Halt On
[All, But Keyboard]
Base Memory
640K
Extended Memory
1790M
higf
: Move
Enter: Select
+/-/PU/PD: Value
F10: Save
ESC: Exit
F1: General Help
F5: Previous Values
F6: Fail-Safe Defaults
F7: Optimized Defaults
Item Help
Menu Level
