- 43 -
BIOS Setup
DRAM Voltage Control
Allows you to set memory voltage.
Normal
Supplies the memory voltage as required. (Default)
1.275V ~ 2.445V
The adjustable range is from 1.275V to 2.445V.
Note: Increasing memory voltage may result in damage to the memory or reduce the useful life of the
memory.
DDR VTT Voltage Control
Allows you to set the memory VTT voltage.
Normal
Supplies the memory VTT voltage as required. (Default)
0.720V ~ 1.050V
The adjustable range is from 0.720V to 1.050V.
Note: Increasing memory voltage may result in damage to the memory or reduce the useful life of the
memory.
NB Voltage Control
Allows you to set the North Bridge voltage.
Normal
Supplies the North Bridge voltage as required. (Default)
0.920V ~ 1.400V
The adjustable range is from 0.920V to 1.400V.
SB/HT Voltage Control
Allows you to set the South Bridge/HT-Link voltage.
Normal
Supplies the South Bridge/HT-Link voltage as required. (Default)
0.940V ~ 1.500V
The adjustable range is from 0.940V to 1.500V.
NB/PCIe/PLL Voltage Control
Allows you to set the North Bridge PCIe PLL voltage.
Normal
Supplies the North Bridge PCIe PLL voltage as required. (Default)
1.450V ~ 2.100V
The adjustable range is from 1.450V to 2.100V.
CPU NB VID Control
Allows you to set the CPU North Bridge VID voltage.
Auto
sets the CPU North Bridge VID voltage as
required. The adjustable range is dependent on the CPU being installed. (Default: Normal)
Note: Increasing CPU voltage may result in damage to your CPU or reduce the useful life of the CPU.
CPU Voltage Control
Allows you to set the CPU voltage.
Auto
sets the CPU voltage as required. The adjustable range is de-
pendent on the CPU being installed. (Default: Normal)
Note: Increasing CPU voltage may result in damage to your CPU or reduce the useful life of the CPU.
Normal CPU Vcore
Displays the normal operating voltage of your CPU.
