6

Dismantling the unit

Turn  off  the  device.  Remove  the  front  panel  and  place  it  into  the  case.  First

remove  the  front  frame  of  the  device  by  inserting  a  flat  object  (e.g.  the  back  of

the  disassembly  key)  between  the  device  and  the  panel  to  the  right  and  left  of

the short side of the frame and carefully levering the panel out towards the

front. Then insert the two release keys into the openings on both sides of the

front of the device and slide these until the stop. Make sure that the protrusion

on the disassembly key points away from the device during the insertion. Slowly

and carefully pull out the device. Remove the cable and antenna from the

device.

Detachable front panel

Install the fastening hole on the right side of the front panel onto the right fastening of the unit. Press on the

left part of the panel until a click. Ensure that the panel is properly fixed.

To detach the front panel, press REL button, then distract the right side of the panel from the fastening of the

unit.

Anti-theft system

The front panel of this unit can be stored in the included protective case when not in used and carried away

when you leave the vehicle to deter theft.

Switch off the power of the unit. Detach the front panel, then put it to the protective case and take it with

you.

Cautions: The control panel can easily be damaged by shocks. After removing it, place it in a protective case

and be careful not to drop it or subject it to strong shocks.

The rear connector that connects the main unit and the control panel is an extremely important part. Be

careful not to damage it by pressing on it with fingernails, pens, screwdrivers, etc.

Note: If the control panel is dirty, wipe off the dirt with soft, dry cloth only. And use a cotton swab soaked in

isopropyl alcohol to clean the socket on the back of the control panel.
