16

Mode selection

Repeatedly press MODE button on the RC or MOD button on the panel

to select a mode: Radio => Disc => USB => CARD => TV => AV-in.

In any mode touch MENU (in the right top corner of the screen) or

press MENU button on the RC to display the Main menu as shown in

the picture. In the menu, touch the item of the mode you need to

select the corresponding mode.

Note: The Disc, USB and CARD modes are only available when a disc, USB

or SD/MMC card is inserted into the unit.

Angle setting

Press and hold repeatedly OPEN/TILT button on the RC or BND/TILT button on the panel to adjust the desired

angle of the monitor. Do not adjust the monitor tilt manually, otherwise it can get damaged.

AV in jack

AV jack is intended to receive audio and video signals by connecting to external device.

Subwoofer

Connect a subwoofer to this unit using the Subwoofer output of this unit. For subwoofer operation an external

amplifier is required.

Dual zone function

DUAL - dual zone function enabling user to listen to radio or watch TV in the front zone, and at the same time

play audio or video from disc, USB or memory card. For Dual zone an external monitor is required having its

own acoustic system and possibility of volume adjustment.

Press and hold POWER button on the front panel or press DUAL button on the RC to enable Dual zone mode

and to select between C-DUAL or D-DUAL.

Dual in Radio/TV/AV-In modes

C-Dual on: When C-Dual is on, all buttons are working regularly, except MUTE (MUTE/SEL), MODE (MOD) and

VOL buttons (VOL regulator). Pressing MUTE or VOL+/- buttons on the RC (or pressing MUTE/SEL button and

rotating VOL regulator on the panel) can control the main unit (cannot control external monitor). Pressing
