26
AUX IN, RCA OUT, SUB OUT & Video OUT
Auxiliary Input
The Auxiliary Input Jack is on the rear of unit. Insert the RCA plugs into the AUX IN jack on the front of the unit.
Route the other end of the RCA to the any external audio device such as MP3. Press and hold the MOD button to
choose AUX. Use the volume control to adjust volume.
RCA Output
The RCA Output Jack is on the back of the unit. (Refer to Wiring Diagram) This output is for connecting amplifier, or
other audio equipment that requires a pre-amp out connection. (Red = Right, White = Left) Follow the
manufacturers instructions for the audio component that you are connecting.
Subwoofer Output
The Subwoofer Output Jack is on the back of the unit, (refer to wiring diagram). This output is for connecting
subwoofer that requires a pre-amp out connection. This is a mono output. Follow the manufacturers instructions for
the audio component that you are connecting. To activate this function press and hold BND/NP/SUB button during
Radio/CD/AUX in mode.
Video Output
The Video Output Jack is on the back of the unit. (Refer to Wiring Diagram) This output (yellow) is for connecting
monitor. You must connect a monitor for car in order to play this unit in DVD/VCD. Consult your dealer for any kinds
of monitors that are suitable to use in car. Press the BND/NP/SUB button to choose between PAL and NTSC mode.
