Specifications
18
ENGLISH
ESPAÑOL
DEUTSCH
FRANÇAIS
ITALIANO
NEDERLANDS
General
Power source .......... 14.4 V DC (10.8 – 15.1 V allowable)
Grounding system ........................................ Negative type
Max. current consumption ........................................ 8.5 A
Dimensions
(mounting size) ...... 178 (W)
×
50 (H)
×
155 (D) mm
(front face) .............. 188 (W)
×
58 (H)
×
19 (D) mm
Weight ...................................................................... 1.2 kg
Amplifier
Maximum power output ...................................... 45 W
×
4
Continuous power output .................................... 25 W
×
4
(DIN45324, +B = 14.4 V)
Load impedance .......................... 4
Ω
(4 – 8
Ω
allowable)
Equalizer (3-Band Equalizer)
(Low) .................................................. Level: ±12 dB
(Mid) .................................................. Level: ±12 dB
(High) .................................................. Level: ±12 dB
Loudness contour
(Low) ..................+3.5 dB (100 Hz), +3 dB (10 kHz)
(Mid) ..................+10 dB (100 Hz), +6.5 dB (10 kHz)
(High) ..................+11 dB (100 Hz), +11 dB (10 kHz)
(volume: –30 dB)
Cassette player
Tape .......................... Compact cassette tape (C-30-C-90)
Tape speed ........................................................ 4.8cm/sec.
Fast forward/rewinding time .... Approx. 100 sec. for C-60
Wow & flutter .......................................... 0.09% (WRMS)
Frequency response ...................... 30 - 16,000Hz (±3 dB)
Stereo separation ...................................................... 45 dB
Signal-to-noise ratio ...................... 61dB (IEC-A network)
FM tuner
Frequency range ............................................ 65 – 74 MHz
87.5 – 108 MHz
Usable sensitivity ......................................................10 dBf
(0.9
µ
V/75
Ω
, mono, S/N: 30 dB)
50 dB quieting sensitivity ........................................ 15 dBf
(1.5
µ
V/75
Ω
, mono)
Signal-to-noise ratio ...................... 70 dB (IEC-A network)
Distortion .......................... 0.3% (at 65 dBf, 1 kHz, stereo)
Frequency response ...................... 30 – 15,000 Hz (±3 dB)
Stereo separation .......................... 40 dB (at 65 dBf, 1 kHz)
MW tuner
Frequency range ........................ 531 – 1,602 kHz (9 kHz)
Usable sensitivity .............................. 18
µ
V (S/N: 20 dB)
Selectivity .................................................. 50 dB (±9 kHz)
LW tuner
Frequency range ........................................ 153 – 281 kHz
Usable sensitivity .............................. 30
µ
V (S/N: 20 dB)
Selectivity .................................................. 50 dB (±9 kHz)
Note:
• Specifications and the design are subject to possi-
ble modification without notice due to improve-
ments.
