8

AUDIO SETTINGS

  While listening to any source...

1

Press

AUDIO

 to select

[AUD CTRL]

.

2

Turn the volume knob to make a selection (see the table below), then press
the knob.

 Repeat

step

2

 until the desired item is selected or activated.

3

Press and hold

 to exit.

•  To return to the previous hierarchy, press

.

Default:

XX

SW LEVEL

–15

 to

+15

 (

0

):

Adjusts the subwoofer output level.

BASS LVL

–8

 to

+8

(

0

):

Adjusts the level to memorize for each source. (Before making
an adjustment, select the source you want to adjust.)

MID LVL

–8

 to

+8

(

0

):

TRE LVL

–8

 to

+8

(

0

):

EQ PRO

BASS ADJ

BASS FRQ

60/ 80/ 100/ 200

:

Selects the center frequency.

BASS LVL

–8

 to

+8

 (

0

):

Adjusts the level.

BASS Q

1.00/ 1.25/ 1.50/ 2.00

:

Adjusts the quality factor.

BASS EXT

B-EX ON

:

Turns on the extended bass.

;

B-EX OFF

:

Cancels.

MID ADJ

MID FRQ

0.5K/ 1.0K/ 1.5K/ 2.5K

:

Selects the center frequency.

MID LVL

–8

 to

+8

 (

0

):

Adjusts the level.

MID Q

0.75/ 1.00/ 1.25

:

Adjusts the quality factor.

TRE ADJ

TRE FRQ

10.0K/ 12.5K/ 15.0K/ 17.5K

:

Selects the center frequency.

TRE LVL

–8

 to

+8

 (

0

):

Adjusts the level.

EQ

NATURAL/ USER/ ROCK/ POPS/ EASY/ TOP40/ JAZZ/ POWERFUL

:

Selects

a preset equalizer suitable to the music genre. (Select

[USER]

 to use the

customized bass, middle, and treble settings.)

B. BOOST

BB-L LV1/ BB-L LV2/ BB-L LV3

:

Selects your preferred bass boost level.

;

BB-L OFF

:

Cancels.

LOUDNESS

LOUD LV1

/

LOUD LV2

:

Selects your preferred low and high frequencies boost

to produce a well-balanced sound at a low volume level.

;

OFF

:

Cancels.

BALANCE

L15

 to

R15

 (

0

):

Adjusts the left and right speaker output balance.

FADER

R15

 to

F15

 (

0

):

Adjusts the rear and front speaker output balance.

SW SET

SW ON

:

Turns on the subwoofer output.

;

SW OFF

:

Cancels.

DTIL SET

LPF SW

LPF THRU

:

All signals are sent to the subwoofer.

;

LPF 85HZ

/

 LPF 120HZ

/

LPF 160HZ

:

Audio signals with frequencies lower than 85 Hz/ 120 Hz/ 160 Hz

are sent to the subwoofer.

SW PHASE

PHAS REV

(180°)/

PHAS NML

(0°):

Selects the phase of the subwoofer

output to be in line with the speaker output for optimum performance.
(Selectable only if a setting other than

[LPF THRU]

 is selected for

[LPF SW]

.)

SPRM SET

SPRM ON

:

Creates realistic sound by interpolating the high-frequency

components that are lost in AAC/MP3/WMA audio compression.

;

SPRM OFF

:

Cancels.

(

Selectable only when playing back an AAC/MP3/WMA

disc or a USB device, except iPhone/iPod.)

V-OFFSET

(Default:

 0

)

–8

 to

+8

(for AUX) ;

–8

 to

0

(for other sources):

Presets the volume

adjustment level of each source. (Before adjustment, select the source you
want to adjust.)

•

[SW LEVEL]

/

[SW SET]

/

[LPF SW]

/

[SW PHASE]

 is selectable only if

[SWPRE]

 is set to

[SWPRE SW]

. (

➜

4

)

•

[SW LEVEL]

/

[LPF SW]

/

[SW PHASE]

 is selectable only if

[SW SET]

 is set to

[SW ON]

.
