Control panel —

KW-XC407

1

 Loading slot

2

 (standby/on attenuator) button

3

  DISP (display) button

4

 MODE button

5

 Cassette compartment

6

 Remote sensor

•  DO NOT expose the remote sensor to

strong light (direct sunlight or artificial
lighting).

7

  AUX (auxiliary) input jack

8

 Number buttons

9

 CD

0

 (CD eject) button

p

 Display window

q

5

 (up) /

∞

 (down) buttons

 PROG

(program)

5

 /

∞

 buttons

w

4

 /

¢

 buttons

e

  SEL (select) button

r

 T

0

 (tape eject) button

t

 Control dial

y

 Reset button

u

 Source buttons—CD/CD-CH, TAPE/AUX,

FM/AM, EX (extra)

Dis

play window

i

  Tuner reception indicators—ST (stereo),

MO (monaural)

o

  Disc information indicators—

 (track/file), TAG (ID3 Tag),   (folder)

;

  Text name indicators—DISC, STATION

a

  Main display, level meter

s

 Clock indicator

d

  EQ (equalizer) indicator

f

  LOUD (loudness) indicator

g

 (Dolby B NR) indicator

h

  Playback disc indicators—MP3, WMA

j

  B.SKIP (blank skip) indicator

k

 Source display

l

  Level meter, volume meter, time countdown

indicator

/

  Playback mode indicators—DISC,

 (folder), RND (random),

RPT (repeat), INT (intro),   (track/file),
MAG (magazine)

z

  Loaded source indicators—   (disc),

 (tape)

Parts identification

Display window
