ENGLISH

38

Specifications

AUDIO AMPLIFIER SECTION

Maximum Power Output:

Front and rear:

50 W per channel

Continuous Power Output (RMS):

Front and rear:

19 W per channel into 4 Ω, 40 Hz to 20 000 Hz at no more
than 0.8% total harmonic distortion.

Load Impedance:

4 Ω (4 Ω to 8 Ω allowance)

Tone Control Range:

Bass:

±12 dB at 60 Hz

Mid-range:

±12 dB at 1 kHz

Treble:

±12 dB at 10 kHz

Frequency Response:

40 Hz to 20 000 Hz

Signal-to-Noise Ratio:

70 dB

Line-Out Level/Impedance:

2.5 V/20 kΩ load (full scale)

Output Impedance:

1 kΩ

Subwoofer-Out Level/Impedance:

2.5 V/20 kΩ load (full scale)

Other Terminal:

CD changer, USB input terminal

TUNER SECTION

Frequency Range:

FM1/FM2:

87.5 MHz to 108.0 MHz

FM3:

65.00 MHz to 74.00 MHZ

AM:

MW:  522 kHz to 1 620 kHz
LW:  144 kHz to 279 kHz

FM Tuner

Usable Sensitivity:

11.3 dBf (1.0 μV/75 Ω)

50 dB Quieting Sensitivity:

16.3 dBf (1.8 μV/75 Ω)

Alternate Channel Selectivity (400 kHz):

65 dB

Frequency Response:

40 Hz to 15 000 Hz

Stereo Separation:

30 dB

MW Tuner

Sensitivity:

20 μV

Selectivity:

35 dB

LW Tuner

Sensitivity:

50 μV
