13

Rear

To display the source selection screen. Press the needed item on the screen to select the corresponding source
sound output through the DUAL-R. If another monitor (rear monitor) is connected to the unit, image/audio of
the rear monitor can be changed from the unit, so you can enjoy separate image/audio in the rear seats.
Press IR-SW button on the RC to change the IR to control front or rear source, and you can control from the
rear monitor.

Audio

To display the audio control screen. Press

 and

 buttons on the screen to select a parameter page, then

press        or

 buttons to adjust the selected parameter.

Video

To display the video control screen. Operation is the same as in audio page above.

System

(in any mode, press and hold MENU/SEL button on the front panel to enter the System setup menu)

To display the system setup screen containing following options:
Clock Sys: set the time display mode (12H/24H).
Key Beep: Turn on/off the button pressing beep signal.
Local Area: Press the needed option to change the radio frequency range region.
Clock Adjust:  Select  the  item  (hours,  minutes,  seconds)  pressing  LEFT/RIGHT  arrow  buttons  on  the  screen,
then adjust the selected item pressing UP/DOWN arrow buttons on the screen.
Touch Adjust: when the touch screen does not work properly, or when operating the unit at first time, the
adjustment is necessary. Accurately touch the mark provided in the screen for more than 2 seconds until
“adjustment succeed” is displayed.
Bass, subwoofer, treble frequency: adjust the corresponding frequency.

Exit

To return to the current mode screen.
