54

Audio sound processing (ASP) configuration

1.  Enter the ASP CONFIG menu.
2.  Use the

 buttons on the panel or

8

/   buttons on the RC or touch

the desired item on the screen to select the desired setting: Bass center
freq, Treble center freq, SUB filter, SUB phase, Bass Q-factor.

3.  Press the

 buttons on the panel or

9

/

:

 buttons on the RC touch

the desired button on the screen to enter the list of values.

4.  Press the

 buttons on the panel or

8

/   buttons on the RC touch

the desired button on the screen to select the desired value.

5.  Press PLAY/PAUSE button to confirm.

Bass center frequency:

 select the Bass center frequency according to the audio source disc: 60 Hz, 80 Hz, 100

Hz, 130 Hz, 150 Hz, 200 Hz.

Treble center frequency:

 select the Treble center frequency according to the audio source disc: 10 KHz, 12.5

KHz, 15 KHz, 17 KHz.

Sub filter:

 set a cut-off frequency of the subwoofer s LPF (low pass filter) and that of the  Small  speakers  HPF

(high pass filter). Crossover frequency setting has no effect if the subwoofer is set OFF and any other speaker set
is  Large .
Select a crossover frequency: 80 Hz, 120 Hz, 160 Hz.

Sub phase:

 if trying to boost the bass output of subwoofer the bass gets more murky. This may indicate that the

subwoofer s output and bass content you hear from other speakers cancel each other out. To remove this problem
change the setting of subwoofer: 0D (subwoofer output in phase), 180D (subwoofer output off phase).

Bass Q-factor:

 when the Bass center is selected and adjusting the Q-factor alters the sharpness of the Bass

output, the larger the Q-factor, the sharper the bass. Select the Bass Q-factor: 1.0, 1.25, 1.5, 2.0.
