18

General information

The display

shows an

error message

(ERROR 1 – 11)

one time.

Possible disc error.

Reset the unit by pressing RESET hole.

Ensure the disc is inserted correctly into

the slot.

Clean or change the disc.

The display

shows an

error message

(ERROR 1 – 11)

repeatedly.

Unit operation error.

Turn to a service center.

Specifications

General

Power supply

12 V DC

Current consumption/Fuse

10 A

Maximum power output

4 x 50 W

Dimensions (L x W x H)

178 x 50 x 150 mm

Temperature range

-20

0

C - +60

0

C

FM stereo radio

Frequency range

87.5 - 108.0 MHz

Presettable stations

18

Sensitivity

12 uV

MW Section

Frequency range

522 kHz-1620 kHz

Presetable stations

12

Sensitivity

30 dB

Disc player

System

Compact disc audio system

Storage support

CD/CD-R/CD-RW/USB/SD/MMC

Format support

CDDA/MP3/WMA

Frequency characteristics

20 Hz-20 kHz

Signal to noise CD

>80 dB

ESP

40 sec. for CD/120 sec. for MP3/300

sec. for WMA

Mounting angle

0 - +/-30

0

Line out

Output:

2 channel RCA line-out (2V)

Specifications are subject to change without notice. Dimensions are approximate.
