Operation

10

Audio parameter setting

Press SELECT button repeatedly

to select a parameter: VOL (volume)
=> BAS (bass) => TRE (treble) =>
BAL (balance) => FAD (fader). Rotate
VOLUME knob to adjust each mode:

•  Bass/Treble: from -6 to 6;
•  Balance: L06 (left) to R06 (right);
•  Fader: from R06 (rear) to F06

(front).

  When equalizer is in any mode

except FLAT, bass and treble are not
adjustable.

Preset equalizer modes

Press SELECT button repeatedly

until FLAT/ROCK/POP/CLASS or
JAZZ equalizer mode is displayed.
Rotate VOLUME regulator to select
equalizer mode.

Clock

Press and hold CLK button to

display the time on the screen. Then
press and hold this button again;
the hour indication will blink. Rotate
VOLUME regulator to adjust hours;
press CLK button to go to minutes;
rotate VOLUME regulator to adjust
minutes. To confirm the adjustment,
press CLK button or leave the unit idle
for several seconds.

Aux input

AUX-in jack is intended for

connecting an external audio
equipment to amplify the sound. If
connection is made correctly, the
audio signal from the external source
will be translated through the acoustics
of the head unit. This enables to
adjust the volume and quality of the

sounding. For example, you can
connect an MP3-player to listen to
tracks using the car acoustic system.

Radio operations

Band select

In Radio mode press BND/MEM

button to select a radio band: F1
(FM1), F2 (FM2), F3 (FM3). 6 stations
can be saved in each band.

Manual/automatical tuning

•  Press

/

 buttons

repeatedly to adjust the needed
frequency manually.

•  Press and hold

 or

button. The radio will seek to the next
down or up strong and clear frequency
station.

Storing and recalling stations

•  Press and hold APS/

button for more than 2 seconds
to automatically find and store 6
strongest stations in the current band.

•  After 6 strongest stations are

saved, press APS/

 button; scanning

of all stored stations will begin.

•  Press CH-/10- and CH+/10+

buttons to select saved channels. If
you want to save a new station in a
preset position, select corresponding
station number with CH-/10- and
CH+/10+ buttons. Then tune to the
needed frequency as described in
“Manual/automatical tuning“ above
and press and hold BND/MEM button.
The new frequency will be saved in
the selected position.
