TRANSLATION OF THE ORIGINAL INSTRUCTIONS
BLADE SAWING MACHINE (JIGSAW)
52G057
CAUTION: BEFORE USING THE POWER TOOL READ THIS MANUAL
CAREFULLY AND KEEP IT FOR FUTURE REFERENCE.
DETAILED SAFETY REGULATIONS
SAFETY RULES FOR LASER DEVICE
•
Use dust-masks when cutting to protect your respiratory system
against produced dust.
•
Carefully check the processed material before cutting to eliminate
possibility of cutting nails, bolts, or other hard objects.
•
Do not cut pipes with the jigsaw.
•
Do not cut objects thicker than allowed in technical specification
for a given material.
•
Prior to operation check if there is enough space under processed
material to avoid table or floor damage with the blade.
•
Hold the jigsaw in closed hand.
•
Ensure the jigsaw does not have contact with the material before
pressing the switch.
•
Do not touch moving parts with your hand.
•
Before cutting floor, wall or other material ensure it does not
contain conductors.
•
Do not put away the jigsaw until it stops moving. Do not switch the
jigsaw on when not holding it.
•
To remove the blade switch the jigsaw off with the switch and wait
until the blade stops moving. Then disconnect the tool from mains
socket.
•
Do not touch the blade or processed material immediately after
finishing the work. Those elements may be hot and cause burns.
•
When you see unusual behaviour of the tool or hear strange noises,
immediately switch off the tool and remove the plug from mains
socket.
•
To ensure proper cooling keep ventilation holes in the jigsaw body
uncovered.
CAUTION! This device is designed to operate indoors.
The design is assumed to be safe, protection measures and
additional safety systems are used, nevertheless there is always
a small risk of operational injuries.
SAFETY RULES FOR LASER DEVICE
Laser device used in the power tool design is the class 1 with
maximum power below 1mW and wavelength 6
5
0 nm. Such device
is not dangerous to your sight, however do not look directly at the
source of the light (temporary blindness hazard).
WARNING.
Do not look directly at the laser beam. It may cause
hazards. Follow the below mentioned safety rules.
•
Use the laser device in accordance to the manufacturer’s
instructions.
•
Do not, either intentionally or unintentionally, point the laser beam
at people, animals or any object other than processed material.
•
Do not bring to accidental pointing the laser beam at outsiders’ or
animals’ eyes for a period longer than 0.
25
second, for instance by
pointing the laser beam at mirrors.
•
Always ensure the laser beam is directed at material, which does not
have any reflective surfaces. Reflective steel sheet does not allow for
laser use, because it might cause hazardous light reflection directed
at operator, outsiders or animals.
•
Do not replace laser assembly with device of other type. Any repair
should be carried out by the manufacturer or authorized person.
LASER LIGHT, LASER RADIATION
DO NOT LOOK AT THE LASER BEAM
LASER DEVICE CLASS 2
Wavelength: 650 nm; Output: < 1 mW
EN 60825-1:2007
GB
Adjustments other than described in this manual put in danger of
exposition to laser radiation!
CONSTRUCTION AND USE
Jigsaw is a hand-operated power tool with insulation class II. It is
driven by a single-phase commutator motor.
The tool is designed for making straight, coarse cuts, curved cuts and
holes in wood, wood-like materials, plastics and metals (provided that
appropriate blade is used). Range of use covers repair and building
works, and any work from the scope of individual, amateur activities
(tinkering).
Use the power tool according to the manufacturer’s instructions
only.
DESCRIPTION OF DRAWING PAGES
Below enumeration refers to the device elements depicted on the
drawing pages of this manual.
1.
Wheel for rotational speed control
2.
Switch
3.
Switch lock button
4.
Adaptor
5.
Dust extraction outlet
6.
Switch for pendulum action setting
7.
Footplate
8.
Guiding roller
9.
Edge guide locking screws
10.
Blade protection
11.
Guard
12.
Blade holder
13.
Laser beam aperture
14.
Laser switch
* Differences may appear between the product and drawing
MEANING OF SYMBOLS
CAUTION
WARNING
ASSEMBLY/SETTINGS
INFORMATION
EQUIPMENT AND ACCESSORIES
1. Blade
- 1 pce
2
. Edge guide
- 1 pce
3
. Dust extraction adaptor
- 1 pce
4. Hexagonal key
- 1 pce
PREPARATION FOR OPERATION
BLADE INSTALLATION
•
Set the switch for pendulum action (
6
) to position “III” and lift the
guard (
11
) (
fig. A
).
•
Use the hexagonal key to loosen fixing screws (
a
) of the blade (
12
)
(
fig. B
).
•
Slide blade to the blade holder (
12
) to mechanical stop (blade teeth
should face forward).
• Important
! Make sure the blade is properly positioned in the
guiding roller (
8
).
•
Tighten previously loosened fixing screws (
a
) of the blade and
ensure the blade is properly fixed.
•
Blade removal is similar to installation, only the sequence of actions
is reversed.
