GB

- 18 -

5.  Before starting the equipment

 5.1 General information

•

All covers and safety devices have to be pro-

perly   fitted before the machine is switched

on.

•

It must be possible for the blade to run freely.

•

When working with wood that has been

processed before, watch out for foreign bo-

dies such as nails or screws etc.

•

Before you actuate the On/Off switch, make

sure that the saw blade is correctly fitted and

that the machine’s moving parts run smoothly.

•

Before you connect the machine to the power

supply, make sure the data on the rating plate

is the same as that for your mains.

5.2 Mounting the saw on a workbench (Fig. 2)

1.  It is better to mount the saw on a solid wood

workbench rather than on a weak plywood

stand  where vibrations and noise are certain

to be a nuisance.

2.  The tools and hardware needed to mount the

saw on a work bench are not supplied with

the saw. Be sure to use equipment of at least

the following size:

Item Quantity

Hex screws M8

4

Gaskets Ø 8 mm

4

Washers Ø 8 mm

4

Hex nuts M8

8

3.  A sound-absorbing foam rubber mat is not

supplied with the saw. It is strongly

recommended to use such a mat, however, in

order to minimize vibrations and noise.

Description:

Soft foam rubber mat:

450 x 250 x 13 mm

Do not overtighten the screws. Leave enough

scope for the foam rubber mat to develop a good

absorbing e

 ect.

Mounting the saw on a workbench, see the Figure

(2) List of components in the illustration:

A:   Saw body

B:   Foam rubber support

C:   Worktable

D:   Flat gasket

E:   Washer

F:   Hex nut

G:   Blocking nut

H:   Hex screw

5.3 Assembly

Caution! Pull out the power plug before carrying

out any maintenance and conversion work on

your fretsaw.

5.3.1 Mounting the saw blade guard and the

sawdust blower facility (Fig. 4/5/6)

•

Put the retention bolt (9) on the radial arm

(19).

•

Slide the saw blade guard (10) onto the reten-

tion bolt (9).

•

Insert the screw (20) through the bore hole of

the retention bolt (9) and the saw blade guard

(10).

•

Use the nut (21) to secure the screw from

falling out.

•

The saw blade guard can be fixed at various

heights with the clamping screw (11).

•

Mount the blow-off device (16) as shown in

Fig. 6.

5.3.2 Changing the blade (Fig. 1/3/7)

•

Turn the clamping screw (14) clockwise in

order  to take the tension off the blade (15).

•

Unscrew the left cover (4).

•

First take the blade out of the top blade hol-

der (13), pressing down the upper pendulum

arm as you do so.

•

Then take the blade out of the bottom blade

holder (8).

•

Pull the blade up and out through the table

insert  (18).

•

Install the new blade in reverse order.

Caution: Always insert the blade so that the

teeth point toward the saw table.

The blade can be inserted in slot a or b;

Slot a: For cuts along the axis of the radial arm.

Slot b: For cuts across the axis of the radial arm.

Tension the blade by turning the clamping screw

(14) anticlockwise (right-hand thread).

5.3.3 Tilting the saw table (Fig. 8)

•

Undo the locking screw (5).

•

Tilt the table (7) to the left until the indicator

(17) points to the required angle value on the

scale (6).

Important: For precision work you should

fi

 rst carry out a trial cut and then re-adjust

the tilt angle as required.
