12

 | English

u

Keep hands away from the sawing area. Do not reach
under the workpiece.

 Contact with the saw blade can

lead to injuries.

u

Only bring the power tool into contact with the work-
piece when switched on.

 Otherwise there is danger of

kickback if the cutting tool jams in the workpiece.

u

Ensure that the footplate always rests securely while
sawing.

A jammed saw blade can break or lead to kick-

back.

u

When the cut is completed, switch off the power tool
and then pull the saw blade out of the cut only after it
has come to a standstill.

 In this manner you can avoid

kickback and can place down the power tool securely.

u

Always wait until the power tool has come to a com-
plete stop before placing it down.

 The application tool

can jam and cause you to lose control of the power tool.

u

Use only undamaged saw blades that are in perfect
condition.

 Bent or dull saw blades can break, negatively

influence the cut, or lead to kickback.

u

Do not brake the saw blade to a stop by applying side
pressure after switching off.

 The saw blade can be dam-

aged, break or cause kickback.

u

Use suitable detectors to determine if utility lines are
hidden in the work area or call the local utility com-
pany for assistance.

 Contact with electric lines can lead

to fire and electric shock. Damaging a gas line can lead to
explosion. Penetrating a water line causes property dam-
age or may cause an electric shock.

Products sold in GB only:

Your product is fitted with an BS 1363/A approved electric
plug with internal fuse (ASTA approved to BS 1362).
If the plug is not suitable for your socket outlets, it should be
cut off and an appropriate plug fitted in its place by an au-
thorised customer service agent. The replacement plug
should have the same fuse rating as the original plug.
The severed plug must be disposed of to avoid a possible
shock hazard and should never be inserted into a mains
socket elsewhere.

Product Description and
Specifications

Read all the safety and general instructions.

Failure to observe the safety and general in-
structions may result in electric shock, fire
and/or serious injury.

Please observe the illustrations at the beginning of this oper-
ating manual.

Intended Use

The power tool is intended for making separating cuts and
cut-outs in wood, plastic, metal, ceramic plates and rubber
while resting firmly on the workpiece. It is suitable for
straight and curved cuts with mitre/bevel angles of up to
45°. Note the saw blade recommendations.

Product Features

The numbering of the product features refers to the diagram
of the power tool on the graphics page.

(1)

On/off switch locking mechanism

(2)

On/off switch

(3)

Stroke rate preselection thumbwheel

(4)

Hex key

(5)

Extraction hose

A)

(6)

Extraction outlet

(7)

Base plate

(8)

Pendulum action adjusting lever

(9)

Saw blade receptacle

(10)

Guide roller

(11)

Saw blade

A)

(12)

Shock protection guard

(13)

Hood for dust extraction

(14)

Handle (insulated gripping surface)

(15)

Anti-splinter guard

A)

(16)

Base plate screw

(17)

Scale for mitre/bevel angles

(18)

Guide for parallel guide

(19)

Locking screw for parallel guide

A)

(20)

Parallel guide with circle cutter

A)

(21)

Circle cutter centring tip

A)

A)

Accessories shown or described are not included with the
product as standard. You can find the complete selection of
accessories in our accessories range.

Technical Data

Jigsaw

GST 700

Article number

3 601 BA7 0..

Rated power input

W

500

No-load stroke rate n

0

min

−1

1450–3200

Stroke

mm

20

Max. cutting depth

– In wood

mm

70

– In aluminium

mm

10

– In steel (unalloyed)

mm

6

Max. cutting angle
(left/right)

°

45

Weight according to
EPTA-Procedure 01:2014

kg

2.1

Protection class

 / II

The specifications apply to a rated voltage [U] of 230 V. These spe-
cifications may vary at different voltages and in country-specific mod-
els.

1 609 92A 5B4 | (10.07.2019)
