5

Let our experts help you with a solution.

Customer Service...

www.fellowes.com

Always call Fellowes before contacting your place of purchase, see the rear cover for contact details.

NEED HELP?

Ensure the machine is on a stable surface.

Check there is enough clear space (min 50cm) behind the machine to allow
items to pass through freely.

Plug the machine into an easily accessible mains socket.

1.

2.

3.

SETTING UP THE LAMINATOR

HOW TO LAMINATE

Switch off the machine at the wall. Allow the machine to cool. The outside of the machine can be cleaned with a damp cloth. Do not use solvents or flammable materials to

polish the machine. Cleaning sheets can be used with the machine. When the machine is warm – run the sheets through the machine to clean any residue off the rollers. For

optimum performance, it is recommended that cleaning sheets are used with the machine regularly. (Cleaning sheet order codes #5320601)

Problem

Possible cause

Solution

No control panel illumination

Machine not switched on

Switch on machine at rear next to plug inlet and at the wall socket

Pouch does not completely seal the item

Item may be too thick to laminate

Check pass through thickness is correctly selected and pass through again

Temperature setting may be incorrect

Check pouch thickness is correctly selected and pass through again

Pouch has waves or bubbles

Temperature setting may be incorrect

Check pouch thickness is correctly selected and pass through again

Pouch is lost in the machine

Pouch is jammed

Operate the release lever and pull out the item by hand

Jamming

Pouch was used ‘open end’ first
Pouch was not centred on entry
Pouch was not straight upon entry
Empty pouch was used

Pouch is damaged after lamination

Damaged rollers or adhesive on rollers

Pass cleaning sheets through the machine to test and clean rollers

Stand-by icon flashing

Machine in ‘Power Save’ mode

Press ‘Stand-by’ button, then press preferred setting

TROUBLESHOOTING

STORAGE & CLEANING

Switch the power on (located at the rear of the machine). The green ‘Standby’
symbol will light up. The machine is now in ‘Standby’ mode.

Press the ‘Standby’ symbol to turn the machine ‘On’. The ‘Safe Start’ function
will automatically select the cold setting.

To select pouch settings, press the + and – buttons to scroll up and down the
control panel. The scale setting will be blue for cold and red for hot settings.

For cold lamination, select the cold setting only (

). For hot lamination,

choose the pouch thickness setting as required (75, 100, 125 microns).

The green ‘Wait’ symbol will flash during warm-up or cool-down periods.
When the machine is ready, the flashing ‘Wait’ symbol will change to a solid
colour and a signal will sound.

Place the document into the open pouch. Ensure the document is centred
against the sealed edge. Use the appropriate pouch size for the document.

Ensure the pouch enters the machine sealed edge first. Keep the pouch
straight and central within the slot, not on an angle. Use the entry markings
as a guide.

Upon exit, the laminated pouch may be hot and soft. To prevent jamming
remove the pouch immediately. Place pouch on to a flat surface to cool. Take
care when handling a hot pouch.

To remove or re-align pouches during lamination, press and hold the reverse
button until the pouch is ejected from the entry slot.

4.

5.

6.

7.

8.

9.

10.

11.

12.
