4

CAPABILITIES

- Plug the machine into an easily accessible socket.
- To prevent electrical shock - do not use the appliance close to water, do not spill water on to the appliance, power cord or wall socket.

DO

 ensure the machine is on a stable surface.

DO

 test laminate scrap sheets and set the machine before final laminations.

DO

 remove staples and other metal articles prior to laminating.

DO

 keep the machine away from heat and water sources.

DO

 turn off the machine after each use.

DO

 unplug the machine when not in use for an extended period.

DO

 use pouches designed for use at the appropriate settings.

DO

 keep away from pets, while in use.

DO

 ensure self-adhesive pouches are only used with the cold setting.

DO NOT

 leave the power cord in contact with hot surfaces.

DO NOT

 leave power cord hanging from cupboards or shelves.

DO NOT

 use appliance if the power cord is damaged.

DO NOT

 attempt to open or otherwise repair the machine.

DO NOT

 exceed the machines quoted performance.

DO NOT

 allow children to use this machine without adult supervision.

DO NOT

 laminate sharp or metal objects (eg: staples, paper clips).

DO NOT

 laminate heat-sensitive documents (eg: tickets, ultrasounds etc) on hot

settings.

DO NOT

 laminate with self-adhesive pouches on hot settings.

DO NOT

 laminate an empty pouch.

IMPORTANT SAFETY INSTRUCTIONS - KEEP FOR FUTURE USE

LAMINATOR CONTROLS

A

On / off switch

B

Standby button

C

Pouch selection buttons, up & down ( , 75, 100, 125 microns)

D

Reverse button (

)

E

Carry handle

F

Pouch / document entry slot

G

Entry support shelf

H

Pouch / document exit

I

Cooling system vents

‘Safe Start’ function

When switched on, the machine has a default ‘Safe Start’ function which is

set to the cold pouch setting. You may select other hot temperature settings if

required. The machine will warm-up and alert the user when it is ready.

‘Reverse’ function

To remove or re-align a pouch during lamination, press and hold the reverse

button until the pouch is ejected from the entry slot.

‘Hot Swap’ function

The Hot Swap function enables the user to instantly switch between thick and

thin pouch settings without any processing delays.

•  For best results, use Fellowes ® brand pouches:

Enhance 80, Impress 100, Capture 125, Enhance 80 - Cold Pouches.

•  For self-adhesive (cold pouches) only use the cold setting.

•  This machine does not need a carrier to laminate. It is a carrier-free

mechanism.

•  Always put the item to be laminated into the appropriate sized pouch.

•  Always test laminate with a similar size and thickness before final process.

•  Prepare pouch and item for lamination. Place item within pouch centred

and touching the leading sealed edge. Ensure the pouch is not too large for

the item.

•  If required, trim excess material from around the item after lamination and

cooling.

•  When working with different pouch thickness’ (temperature settings) it is

recommended to first start with the thinnest pouches.

FEATURES & TIPS

Performance

Format

A3 or A4

Entry width

A3 = 318mm

A4 = 240mm

Pouch thickness (min)

75 microns (per side)

Pouch thickness (max)

125 microns (per side)

Warm up time (estimate)

5-6 minutes

Cool down time

60-90 minutes

Lamination speed (+/- 5%)

approx. 30-40cm/min (variable)

Number of rollers

2

Ready indication

Light & beep

Reverse

Yes

Clear Path / Anti-jam engine

Yes

Cold lamination

Yes

Technical Data

Voltage / Frequency / Current(Amps)

A3 = 220-240V AC, 50/60Hz, 2.2A

A4 = 220-240V AC, 50/60Hz, 2.0A

Wattage

A3 = 480 Watts

A4 = 430 Watts

Dimensions (HxWxD)

A3 = 570 x 155 x 108 mm

A4 = 450 x 143 x 108 mm

Net weight

A3 = 2.1 kg

A4 = 1.8 kg

Max document thickness

(laminating capacity)

1 mm
