en
Assembly
16
MH 4005 / 5005 R
Fitting the handlebar (5)
Fasten the 2 handlebars (5-1) to support
by inserting the through screw (5-2), spacer
(5-3), washers (5-4) and nut (5-5) in the up-
per hole of the handlebar.
Proceed in the same way for the lower hole
(5-9), by fitting the other screw (5-2), spacer
(5-3) and the washers h.4 (5-6) in the knob
(5-7) and knob (5-8) complete with nut, in the
sequence shown in the illustration (5).
ADVICE
To prevent fraying the Bowden cables,
guide the Bowden cables between the
through bolts (5-2) and spacers (5-3)!
For more information, see Setting the
handlebar.
Assembly of throttle lever (6)
Secure the throttle cable to the handlebars
using a screw and hexagon nut.
Assembly of control cable (7)
Secure the control cable (7-1) to the right
handlebar (7-3) using a screw (7-2).
CAUTION!
Guide the handlebar (7-3) between both
control cables.
STARTUP
Only start up the machine, after assembly is fully
completed.
CAUTION!
Fill with oil and petrol before initial start-
up. For this purpose, consult the supp-
lied operating instructions from the petrol
motor manufacturer.
Setting the handlebar (5)
The handlebars are height-adjustable.
1 Unscrew knobs (5-7) and (5-8), and insert the
through bolt (5-2) into the hole that best suits
your working requirements.
For side-adjustable version only:
2 The handlebars can be turned right or left by
lifting the lever shown in (5-10).
Transport wheel
The cultivator can be easily rolled to the place of
operation using the transport wheel.
1 The transport wheel should be removed
when operating the cultivator.
Depth skid setting (2)
To ensure that the cultivator properly tills and
moves properly forward, the height of the
depth skid (2-1) should be set via the fixing
screw (2-2) so that the machine maintains a
level operating position.
Once set to the correct position, tighten the
fixing screw (2-2).
Starting the motor (6)
When starting the motor, the tiller blade clutch le-
ver may not be activated.
1. Move the throttle lever to the "START" posi-
tion.
2. Pull out the cable starter briskly, and then al-
low it to wind back in slowly.
Switching on the tiller blades (8)
1. Push clutch lever up fully and hold it there.
The tiller blades may begin to turn when the
lever is only pressed halfway up.
Switching off the tiller blades (8)
1. Release the clutch lever.
Switch on the reverse gear (9)
1. Pull up the reverse gear lever up to the stop.
Switching off the reverse gear (9)
1. Release the reverse gear.
Switching off the motor (6)
1. Move throttle lever to the "STOP".
MAINTENANCE AND CARE
CAUTION!
Risk of injury!
Always switch the motor off and pull
the spark plug connector prior to any
maintenance and care work.
Motor may continue running. Make
sure that the motor has stopped af-
ter switching it off.
Always wear work gloves when car-
rying out maintenance and care jobs
on the cutting blade.
