6

FAN SPEED

AIR SWING

MODE

TEMP

OFF/ON

TIMER

SET

CANCEL

ON

OFF

1

2

3

SET

CLOCK

RESET

OFF

TIMER

ON

TIMER

FAN

SPEED

AIR

SWING

AUTO
HEAT

COOL

DRY

3

4

5

6

7

1

8

2

9

REMOTE CONTROL

Maximum distances: 8m

INDICATOR

POWER

(Green)

TIMER

(Orange)

Remote Control display

Press the remote control’s button

1

TO TURN ON OR OFF THE UNIT

•  Please be aware of the OFF indication on the remote

control display to prevent the unit from starting/stopping

improperly.

2

TO SET TEMPERATURE

•  For heat, cool and dry modes, the range of temperature

for selection is 16°C ~ 30°C.

•  Operating the unit within the recommended temperature

could induce energy saving.

HEAT mode : 20

˚

C ~ 24

˚

C.

COOL mode : 26

˚

C ~ 28

˚

C.

DRY mode : 1

˚

C ~ 2

˚

C lower than room temperature.

3

TO SELECT OPERATION MODE

AUTO mode - For your convenience

•  Unit selects the operation mode according to the room

temperature.

•  Once auto mode is selected, the unit will operate at the

standard setting temperature.

Room

temperature

Operation mode

Standard setting

temperature

23

˚

C & above

Cool

25

˚

C

Below 23

˚

C

Dry

22

˚

C

Below 20

˚

C

Heat

21

˚

C

• Press

 for “HI” to +2

˚

C or

 for “LO” to -2

˚

C to the

standard setting temperature.

HEAT mode - To enjoy warm air

•  Unit takes a while to warm up. The power indicator blinks

during this operation.

COOL mode - To enjoy cool air

•  Use curtains to screen off sunlight and outdoor heat to

reduce power consumption during cool mode.

DRY mode - To dehumidify the environment

•  Unit operates at low fan speed to give a gentle cooling

operation.

4

TO SELECT FAN SPEED (3 OPTIONS)

FAN SPEED

•  For AUTO, the indoor fan speed is automatically adjusted

according to the operation mode.
